Semi-autoclave Immersion Type Autoclave (Retort)

Semi-autoclave Immersion Type Autoclave (Retort) thumbnail-1
Semi-autoclave Immersion Type Autoclave (Retort) photo-1
US$ 6,850 - 61,200 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
HH
Contact Supplier Request Quote Chat Now
Hangzhou Huihe Machine Facture Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name HH
Model Number DN1200*3000
Usage Diary Product
Type Autoclave
Voltage 380V
Power(W) 10Kw-700Kw
Weight 800kg
Dimension(L*W*H) 1500*900*1900mm
Certification CE ISO
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas

Hot water immersion sterilization controlled with precise temperature and pressure by PLC two sets of autoclave use the same sterilizing water one after another. The hot sterilizing hot water inject to another autoclave after finishing on batch to decrease heat and water consumption.



Model

RJD-500

RJD-700

RJD-900

RJD-1000

RJD-1100

RJD-1200

RJD-1300

RJD-1500

Sterilizing Tank

ID (mm)

500

700

900

1000

1100

1200

1300

1500

Height (mm)

800

1200

1500

2000

2400

3000

3750

3750

Volume of the Inside Tank (m3)

0.2

0.5

1

1.8

2.5

3.5

5.2

7

Sterilizing Baskets

1

2

2

2

3

4

4

4

Steam Consumption kg/cycle

85

150

250

285

350

385

420

500

Design Temperature (°C)

147

Design Pressure (Mpa)

0.35

Steam Work Pressure (Mpa)

0.4-0.6

Cooling Water Work Pressure (MPa)

0.3

Compressed Air Work Pressure (Mpa)

0.7

Outside Sizes

L (mm)

1150

1650

2050

2600

3050

3700

4500

5650

W (mm)

750

950

1150

1250

1350

1450

1550

1750

H (mm)

1000

1200

1400

1500

1600

1700

1800

2050





 Semi-autoclave Immersion Type Autoclave (Retort)Semi-autoclave Immersion Type Autoclave (Retort)Semi-autoclave Immersion Type Autoclave (Retort)Semi-autoclave Immersion Type Autoclave (Retort)
