Home > Products > Concentration Evaporation Crystalization Equipment > Advanced Vacuum Beverage Concentration Tank
Advanced Vacuum Beverage Concentration Tank
- ningbo or shanghai port
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | hh | Model Number | hh-0021 | |
| Processing Types | Carbonated Beverage | Voltage | made to order | |
| Power(W) | 5 Kw | Weight | 250Kg | |
| Dimension(L*W*H) | 1900*1100*2300 | Certification | CE | |
| Warranty | 12 months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Product information:
The roundness concentration tank, consisting of main body, condenser, gas-liquid separator and liquid receiving barrel, serves to concentrate, distil the material liquid and reclaim organic menstrual in the pharmacy, foodstuff and chemistry. The concentration under reduced pressure brings short time of concentration and prevents the destruction of the effective content in the thermal sensitive material. The fact that the part in contact with the material is made with stainless steel brings qualified anticorrosion performance, meeting with the GMP standard.
Technical Pramaters:
Model | QN-300 | QN-500 | QN-700 | QN-1000 |
Evaporation KG/H | 70 | 120 | 145 | 195 |
Volume | 300L | 500L | 700L | 1000L |
Jacket pressure | 0.09Mpa | |||
Vacuum degree | 500-620mmHg | |||
Heating area | 1.3 | 1.6 | 2 | 2.8 |
Condensation area | 2.4 | 3 | 3.5 | 4 |
Weigh KG | 380 | 450 | 630 | 950 |
Length mm | 1900 | 2030 | 2100 | 2335 |
Width mm | 1100 | 1200 | 1300 | 1520 |
Height mm | 2300 | 2500 | 2600 | 2765 |
Contact Us
- Hangzhou Huihe Machine Facture Co., Ltd.
- Contact nameAwen Wu Chat Now
- Phone86-571-89774695
- AddressNo. 33, Tangkang Road, Yuhang District, Hangzhou, Zhejiang, China
