Help CenterBig Recycling Capacity Circular Round Concrntrator
Related Products
-
Big Recycling Capacity Circular Concrntration CanUS$ 8,400 - 21,480MOQ: 1 Unit -
Sell Triple-effect ConcentratorUS$ 4,500 - 9,999MOQ: 1 Case
-
QN-series Vacuum Pressure Reduction Concentration TanksUS$ 25,000 - 40,000MOQ: 1 Piece
-
Vacuum Pressure Reducing Concentrating SystemUS$ 4,000 - 19,999MOQ: 1 Piece
-
Advanced Vacuum Beverage Concentration TankUS$ 6,000 - 19,999MOQ: 1 Piece
The circular concentration can, consisting of four parts of can body, condenser,gas-liquid separator and liquid receiving barrel, is available to concentrate and distill the material liquid in such industries as pharmacy, food and chemistry and recycle the organic menstruum . The adoption of reduced pressure concentration shortens the time for concentration, avoiding the destruction to effective component inside the thermal sensitive material. The contact part of the concentrator
and the material is made with the stainless steel, resistan to corrosion and high durable, meeting the standard of the GMP.
Technology parameter:
Mode |
QN-300 |
QN-500 |
QN-700 |
QN-1000 |
|
Evaporation capacity (Kg/h) |
70 |
120 |
145 |
195 |
|
Volume(L) |
300 |
500 |
700 |
1000 |
|
Jacketed pressure(Mpa) |
0.09 |
||||
Degree of vacuum (mmHg) |
500-620 |
||||
Heating area (m) |
1.3 |
1.6 |
2 |
2.8 |
|
Cooling area(m) |
2.6 |
3.5 |
4 |
5.6 |
|
Outline size(mm) |
L |
1900 |
2030 |
2100 |
2335 |
W |
1100 |
1200 |
1300 |
1520 |
|
H |
2300 |
2500 |
2600 |
1765 |
|
