Home > Products > Wheat Combine Harvester > 4LZ-1.5 Wheel Type Self-propelled Mini Wheat Combine Harvester
4LZ-1.5 Wheel Type Self-propelled Mini Wheat Combine Harvester
- Qingdao Port
- T/T Money Gram Credit Card
You May Like
Product Details
| Condition | New | Type | Combine Harvester | |
| Usage | Grain Harvester | Place of Origin | Shandong, China | |
| Brand Name | Dafeng King | Model Number | 4LZ-1.5 | |
| Certificate | Other, ISO |
Product Description
Specifications
4LZ-1.5 Wheel Type Self-propelled Mini Wheat Combine Harvester+ 1800mm cutter blade
+ 55 Hp diesel engine
4LZ-1.5 Wheel Type Self-propelled Mini Wheat Combine Harvester
Technical specification:
Technical specification sheet | ||||
Type |
| Wheel full feed self-propelled | ||
Model |
| 4LZ-1.5 | ||
Cutting Width | mm | 1800 | ||
Feed | Kg/s | 1.5 | ||
Running speed | Km/h | 2.48-16 | ||
Diesel Engine | Model |
| 4L68 | |
Power | KW | 40 | ||
Rotate Speed | r/min | 2600 | ||
Average Oil Consumption per Hectare | Kg/hm² | ≤27 | ||
Working Productivity | Mu/H | 4-6 (0.27-0.4Hec/H) | ||
Total Weight | kg | 2800 | ||
Dimension (L×W×H) | mm | 5800 | ||
2400 | ||||
3000 | ||||
Ground Clearance | mm | 310 | ||
Conveyer | Type |
| Flat belt raked tine | |
Width | mm | 400 | ||
Threshing Drum | Type |
| Transverse Axial Flow | |
Diameter | mm | Φ545 adjustable | ||
Length | mm | 1350 | ||
Re-sthreshing Drum | Type |
| Axial flow cutting plate | |
Diameter | mm | Φ190 | ||
Concave | Type |
| Grid based | |
Angle | (°) | 236.8 | ||
Separation Area | m² | 1.38 | ||
Sieves | Type |
| Double sieves + fan + re-threshing | |
above sieve | m² | 0.76 | ||
bottom sieve | m² | 0.92 | ||
Fan | Type |
| Low-pressure, volute | |
Diameter | mm | Φ346.8 | ||
Unloading type |
|
| mechanical | |
Tank capacity |
| m3 | 1 | |
Chassis | Type |
| 4×2 wheeled | |
Gear box |
| 3×2+1 | ||
Wheelbase | mm | 1985 | ||
Oil Tank Capacity | L | 65 | ||
Operator |
| 1 Person | ||
Qty’/40HC | Sets | 2 | ||
