4LZ-2.0D Gain Combine Harvester

Specifications

+ 4LZ-2.0D Gain Combine Harvester
+ 2000 mm cutter bar
+ 75HP diesel engine
+ HST transmission
+ Double threshing cylinder

4LZ-2.0D Gain Combine Harvester :

self-propelled full feeding grain combine harvester with rubber track



A. Rice & Wheat Combine Harvesters

Type: 4LZ-2.0D

FOB Qingdao Port Price: $ /set

Time of delivery: 7days

Type of Payment: T/T or L/C

B. Main Features:

1.    75 HP diesel engine, 2 meters cutting width, Auto Transmission, high efficiency.

2.     Double axial flow threshing cylinders and adjustable front & rear sieving plates ensure the grain more clean, less breakage and less loss.

3.     Big width conveyer groove with innovated cutter bar lifting system can provide a more efficient feeding and a higher lifting level, convenient for working in paddy field and maintenance, and lower noise and vibration.

4.     Lower ground pressure, better for passing in paddy field.

5.     Extremely strong Chassis; Excellent waterproof suspension wheel system; Easier turning & control with friction disc brake and special heavy-duty gearbox for hydraulic steering combine harvester.

C. Technical Specifications:

Model	4LZ-2.0D
Working Efficiency	0.53 ~ 0.80Ha./H (1.32 ~ 2.00Acre/H)
Overall Dimensions (L x W x H)	4700×2300×2700 mm
Weight	2400 kg
Engine	Diesel Engine
Model	498BZT
Rated Power	75 HP (55kw) / 2400 rpm
Fuel consumption per hectare	≤30 Kg/Ha.
Chassis
Rubber Track	400x90x48
Transmission	HST F:3 / R:3
Ground Pressure	≤18 Kpa
Min. Ground Clearance	240 mm
Header
Cutting Width	2000 mm
Type of Lifting	Hydraulic
Lifting of Reel	Hydraulic
Steering	Hydraulic
Conveyor	Chain rack tooth type
Threshing Cylinder	Tangential Flow + Axial Flow, Dual Spike-tooth type
Cleaning	Fan (front blowing + rear suction)+Sieving+re-thresher
Paddy fill Method	Grain Tank & Bag
Grain Tank	1.1 CBM/ (500-550 kg)
Total Loss
Rice	≤3%
Wheat	≤1.2%
Breakage	≤1.5%
Impurity	≤2.0%
