sludge dewatering :Features:
The decanter centrifuge can be adjusted to suit individual requirements by varying:
1. Decanter centrifuge bowl speed to ensure the exact relative centrifugal force required for optimized separation.
2. Decanter centrifuge differential speed, for optimized balance between liquid clarity and solids discharge capacity.
3. Decanter centrifuge pond depth in the bowl for optimized balance between liquid clarity and solid dryness.
Application:
Decanter centrifuge is widely used in industries as municipal and industrial waste water treatment, food processing, pharmaceuticals and chemicals, etc.
1. Decanter centrifuge solid phase dehydration: dehydration effect for processing materials of solid particles.
2. Decanter centrifuge particle size classification: used in the removal of material of large diameter solid particles.
3. Decanter centrifuge liquid clarification: used for removing solid particles in the suspension liquid are clarified.
Working Principle:
Decanter centrifuge separation takes place in a horizontal cylindrical bowl equipped with a scroll conveyor. The processing material is fed into the bowl through a stationery inlet tube and is smoothly accelerated in the accelerate chamber. Centrifugal forces cause instant sedimentation of the solids on the wall of the bowl. The conveyor rotates in the same direction as the bowl, but at a different speed, thus moving the solids towards the conical end of the bowl.
Technical Parameters:
Model | Diameter | Max. Speed | Separation Factor | Capacity (M3/H) | Power | Weight (kg) | Overall Size |
LW250×1000 | 250 | 5400 | 4080 | 2-10 | 11-15 | 1000 | 2600×760×1115 |
LW300×700 | 250 | 4600 | 3553 | 2-10 | 11-15 | 1120 | 2335×814×1170 |
LW300×1000 | 300 | 4600 | 3553 | 2-10 | 11-18.5 | 1380 | 2635×814×1170 |
LW350×1000 | 350 | 4200 | 3450 | 2-18 | 15-30 | 1950 | 2712×872×1244 |
LW350×1320 | 350 | 4200 | 3450 | 3-22 | 22-30 | 2200 | 3012×872×1244 |
LW350×1550 | 350 | 4200 | 3450 | 2-18 | 15-30 | 1950 | 2800×1380×850 |
LW430×1320 | 430 | 4000 | 3845 | 4-28 | 22-37 | 2500 | 3120×940×1320 |
LW430×1600 | 430 | 4000 | 3845 | 4-28 | 22-37 | 2500 | 3000×1500×1000 |
LW430×1800 | 430 | 4000 | 3845 | 4-28 | 22-37 | 2950 | 3600×940×1320 |
LW480×1800 | 480 | 3650 | 3580 | 6-35 | 37-45 | 4550 | 3650×1010×1396 |
LW480×2000 | 480 | 3650 | 3580 | 8-40 | 45-55 | 5050 | 3850×1010×1396 |
LW500×2000 | 500 | 3500 | 3423 | 8-40 | 45-55 | 5800 | 4150×1380×1558 |
LW530×2120 | 530 | 3500 | 3630 | 10-50 | 45-75 | 7200 | 4270×1380×1558 |
LW530×2200 | 530 | 3500 | 3630 | 10-50 | 45-75 | 7200 | 3800×2350×1200 |
LW580×2120 | 580 | 3000 | 29180 | 12-55 | 55-75 | 7800 | 4290×1450×1638 |
LW650×2400 | 650 | 2800 | 29180 | 15-60 | 75-90 | 8300 | 4330×1560×1768 |
