crawler excavators price famous brand and new full hydrauliJINGONG JGM923

Name: crawler excavators price famous brand and new full hydrauliJINGONG JGM923
Brand: Jingong
Price: USD $90,000 - 120,000 / Set

FOB Price

USD $90,000 - $120,000 / Set

1 Set(Min.Order)

Supply Ability 1900 Piece / Pieces per Month
Port XIAMEN
Payment Terms:T/T L/C D/P D/A

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Fujian, China	Brand Name:	Jingong	Model Number:	JGM923 Crawler excavator crawler excavators price
Condition:	New	Moving Type:	Crawler Excavator	Operating Weight:	22300KG
Bucket capacity:	1.1M3	Maximum Digging Height:	9388MM	Maximum Digging Depth:	6758MM
Machine Weight:	22300KG	Max Digging Radius:	9765MM	Rated Speed:	3.4km/hr
Certification:	ISO9001	After-sales Service Provided:	Overseas third-party support available

Product Description

Competitive Price China New 23T Crawler Excavator(JGM923Made In China)For Sale

Excavator parameters

Main Parameters
Operation Weight(Standard Configuration) (KN)	22320
Standard Bucket Capacity	1
Transport Dimensionsmm	960029902840
Bucket Digging Force (KN)	135
Bucket Rob Digging Force (KN)	110
Maximum Torque	697/1800
Device
High-low Speed (Km/h)	6.15/3.4
Climbing Performance(°)	30
Total Length of the Crawler	4443
Tail Turning Radius (mm)	3075
Width of the Crawler	600
Ground Pressure (Kpa)	44
Turning Mechanism
Turning Speed (rpm)	11.8
Engine
Model	Cummins 6BTA5.9-C
Form	Six Cylinders, Straight, Four Strokes, Direct Injection, Turbocharger, Air Inter Cooling
Rated Power/Rotate Speed (KW/rpm)	124/2000
Rated Torque/Rotate Speed (N.m/rpm)	651/1500
Cylinder Diameter*Stroke (mm)	102*120
Output Value (L)	5.9
Fuel Consumption (g/KW.h)	215
Hydraulic System
Fuel Tank Capacity (L)	428
Main Valve Consumption(ML)	112*2
Main Valve Pressure(MPA)	34.3
Operating Scope
Maximum Digging Height (mm)	9416

Standard equipment:

1. Engine (Original import Cummins 68TA5.9-C )
2. Hydraulic oil, oil (Shell or Mobil)
3. Main hydraulic pump (Original import Japan Kawasaki brand)
4. High energy maintenance-free battery (2×12V-120hA)
5.Main valve (Original import Japan Kawasaki brand)
6. Starter motor (24V-5kW)
7. Pilot control valve (Original import Japan Kawasaki brand)
8.Anti-swing during slewing
9. Slewing motor (Original import Japan Kawasaki brand)
10. Slewing priority
11.Travel motor (Original import Japan Kawasaki brand)
12. Travel straight retaining
13. Hydraulic oil cylinder (Original import Japan Kayaba )
14.Dual-speed shift automatically during

15. Hydraulic accessories (Manuli, Parker)
16. Heavy duty slewing support (sealed lubricaiton)
17.Track shoe (Italy)

18. Lifting hold
19.Electronic monitoring and operating system
20. Rearview mirror
21.Air conditioner for crawler excavators price only
22.Standard working appliance
23.Standard bucket(1.1m3)
24.Advanced audio
25. Advanced Seats (Grammer)
26. Centralized lubrication
27.High quality radiating system made by joint venture enterprises
28. Ergonomically designed all-weather cab
29.Advanced imported paint

JGM923 Excavator in construction site

Our after sale service team

....

Contact Us

Fujian Jingong Machinery Co., Ltd.: Contact nameLISA LEE; Phone86-595-85751583; AddressQianpu Industrial Area, Anhai, Jinjiang
