China Quality Artificial Sand washing machine
1.Brief Introduction to sand washing machine
Sand Washing Machine is used to remove the mud or silt in sand. The mining machine aims at improving the quality of sand. The materials include the required gravelin building-site, gravel factories, hydropower station and concrete dam site, post and electric pole factory, casting-70 sand, glass factory's quartz sand and refilling pressure sand.
Sand washer (sand washing machine) is widely used for cleaningmaterials in the following industries: quarry, minerals, building materials,transportation, chemical industry, water conservancy and hydropower, cementmixture station and so on.
Sand washing machine Features:
1) The sand washing machine is Simple structure
2) The industry washing machine is Water saving
3) The sand washer is No pollution
4) The sand washing machine is Easy to maintain
5) Good durability
2.Specification of sand washing machine :
Parameter Type | YLSWM2200 | YLSWM2600 | YLSWM2900 | YLSWM3500 | |
Wheel bucket diameter(mm) | 2200 | 2600 | 2900 | 3500 | |
Speed(r/min) | 1-2 | 1-2 | 0.8-1.5 | 0.8-1.2 | |
Capacity(t/h) | 15-30 | 20-50 | 50-100 | 120-200 | |
Motor power(kw) | 5.5 | 7.5 | 11 | 15 | |
The above dynamo is used the excitation speed regulation dynamo . | |||||
Total weight(kg) | 4300 | 5600 | 8100 | 9900 | |
Overall dimension (L*W*H)(mm) | 3150×1910×2280 | 3520×2390×2690 | 3820×2640×3200 | 4420×2930×3800 | |
Material | 45#Carbon board | 45#Carbon board | 45#Carbon board | 45#Carbon board | |
Wear resistant layer | 65# manganese steel plate | 65# manganese steel plate | 65# manganese steel plate | 65# manganese steel plate | |
Thickness of the iron flate | 6mm | 6mm | 8mm | 10mm | |
All the thickness could used as the request of the customer. | |||||
Model of reducer | ZQ350 | ZQ400 | ZQ400 | ZQ500 | |
Sand washing machine working on site
Sand washing machine---The bigger stones will be separated by the hopper
Multi-separating&discharge----The three kinds separated materials will be discharged by conveyor belt.
Sand washing machine used on sand dredger. After the sand is digged up, the sieve will separate the stones and gravels, the sand will be further washed by the wheel.
Sand washing machine used on land
sand washing machine
The gravels and sand will be transported aside by the conveyor belt
The sand washing machine could be customized. Please inform us of your specific requirements.
