Iron Sand Extracting Ship for Gravity Concentraction
US$ 42,000 - 52,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Cutter Suction Dredger, Separator
Power Type:
Gasoline
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Iron Sand Selecting MachineUS$ 60,000 - 160,000MOQ: 1 Set -
Iron Sand Selecting Machine , Mining EquipmentUS$ 50,000 - 120,000MOQ: 1 Set
-
Professional Iron Ore Mining Equipment , Iron Ore MachineryUS$ 30,000 - 100,000MOQ: 1 Set
-
Water Use Iron Sieving Dredger Machine for Ore Gravity SelectionUS$ 50,000 - 74,000MOQ: 1 Set
-
80 M3/h China Bucket Chain Dredger Sand Dredging and Washing MachineUS$ 30,000 - 150,000MOQ: 1 Set
Condition
New
Type
Other, Cutter Suction Dredger, Separator
Power Type
Gasoline
Dredging Depth
10 m
Draught
90 cm
Place of Origin
Shandong, China
Brand Name
YUANHUA
Model Number
8inch
Weight
32t
Certification
ISO 9001:2008 Certification
Warranty
6 months
After-sales Service Provided
Engineers available to service machinery overseas
Iron Sand Extracting Ship
Below are the technique specifications of 8 inch Pump Iron Sand Dredger
other models are available
| YUANHUA Pump Iron Sand Dredger |
| Working mode: pump sand from water - separate stone through simple sieve - enter the water tank - materials flow steady into the magnetic roller through the slide board - iron extraction - iron sand being discharged to shore by sand pump which is driven by diesel engine - wastes being dumped through chute |
| Features: Simple control High efficiency Easy to disassemble and transport High recovery rate Low cost Long serving life |
| (1) Hull |
| Dimension: 13.5m×1.5m×900mm (L*W*H) side floating bodies/double |
| Engine Room: 2m×1.5m×1m (L*W*H) middle floating body |
| Anti-rust primer painted at the bottom |
| Anti-rust coating painted at the surface |
| Body:4mm steel plate |
| Deck:3mm anti skid plate |
| Engine Room: 5mm steel plate |
| Total Width: 4.5-5m |
| Height of holding frame:4.2-5.5m |
| (2) Sand Pump Unit |
| Model: 8 inch |
| Suction:200mm Discharge:200mm |
| Capacity:80M³/h (consistency 20%) |
| Fitted Power:59kw Speed:700rpm |
| Suction Depth:15m |
| Driving Engine:HFR4105IZG WEIFANG·HUAYUAN |
| Speed:2000rpm Power:74kw |
| Oil Consumption:≤197g/kw.h |
| Water Pumping Unit: |
| Capacity:100M³/h Head:15m |
| Fitted Power: 20HP diesel engine |
| (3) Magnetic Separation Equipment (permanent magnet roller type) one set |
| Size:3000mm×900mm (water-washing precise selection type) |
| Antimagnetic angle:120° |
| Selection Mode: downstream type/forward flow |
| Super Antimagnetic Top Magnetic Force: 4300GS |
| Recovery Rate: 90% net selection |
| Fitted Power: 7.5kw standard motor Model 350 reducer |
| Iron Sand Grade:50-55 depend on original ore magnetic holding rate |
| 7.5kw submersible pump one set |
| (4) Winch |
| ladder rising winch 4kw electric winch one set |
| Hand operating winch two set |
| (5) Simple Control Room |
| Light two set |
| (6) Power Unit |
| Model:HFR4100ZD WEIFANG·HUAYUAN |
| Generating Power:30kw Speed:1500rpm |
| Rated Current:72A Rated Voltage:400V |
| Oil Consumption: ≤197g/kw.h |
| (7) Propeller |
| Impeller Diameter:500mm Length:1.8m |
| Fitted Power:20HP diesel engine |
| (8) Iron Sand Discharging Pump |
| Model:4 |
| Fitted Power:24HP diesel engine |
| (9) Attachments |
| Main pump 8inch impeller 3pcs |
| Water pump 4inch impeller 5pcs |
