Model |
| LG6210 | LG6225 |
Operating weight | Kg | 21200 | 21800 |
Bucket capacity | m3 | 0.9 | 1.0 |
Diesel engine model |
| Cummins Tier-2 | Komatsu Cummin Tier-2 |
Rated power | kW | 112 | 112 |
Rated RPM | rpm | 1950 | 1950 |
Max. flow rate of hydraulic system | L/Min | 2×208 | 2×208 |
Max. operating pressure of hydraulic system | MPa | 31.5/34.3 | 31.5/34.3 |
Length of track | mm | 4070 | 4270 |
Width of track | mm | 600 | 600 |
Min. clearance from ground | mm | 472 | 472 |
Max. digging reach | mm | 9750 | 9750 |
Max. digging depth | mm | 6610 | 6610 |
Max. digging height | mm | 9250 | 9250 |
Max. dumping height | mm | 6620 | 6620 |
Max. bucket digging force | kN | 127 | 127 |
Max. arm digging force | kN | 98 | 98 |
Swing speed | rpm | 11.6 | 11.6 |
Travel speed | km/h | 5.5/3.3 | 5.5/3.3 |
Boom swing angle(left/right) | ° | 50/86 | 50/86 |
Overall dimension | mm | 9439×2809×2978 | 9439×2809×2978 |
Optional implements |
| Rock bucket/rock breaker |
|
The technical options of the dredgers are customized and truly flexible
--totally up to the customer's requirement and the working environment.
I need to know more about your local working condition in order to offer a best solution for your project.
