Specification
Model | 4LZ-1.8 | ||
Dimension (Length*Width*Height) mm | 4400*2300*2700 | ||
Weight (kg) | 2250 | ||
Working efficiency (ha./h) | 0.26~0.53 | ||
Cutter bar length (mm) | 1800/2000/2200 | ||
Engine | Type | Water cool, four stroke, diesel engine | |
Model | 498BT | ||
Displacement (L) | 2.98/3.16 | ||
Output/rpm (kw/rpm) | 45/2600 | ||
Fuel tank capacity (L) | 40 | ||
Traveling system | Crawler specification (width*pitch*No.of tooth) | 350mm*90mm*46 | |
Ground pressure (kpa) | 21 | ||
Ground clearance | 250mm | ||
Transmission | 4 forward, 2 reverse/HST | ||
Working parts | Threshing cylinder | Type | Axial flow, spike tooth |
Diameter& length | 550mm*1285mm | ||
Cleaning | Chaffer sieve + fan( front blowing and rear suction) + two times vibrate | ||
Fuel consumption (kg/ha.) | 22~42 | ||
Working speed (m/s) | 0.5~1.2 | ||
Grain tank capacity (cubic meter) | 0.8/0.9 | ||
Wet field passing | 15cm | ||
Grain unloading method | Sacks/unloading auger | ||
Total loss (%) | Rice<3,Wheat<1.5 | ||
Breakage rate (%) | <2 | ||
Impurity rate (%) | <2 | ||
Optional device | Continuosusly Variable Transmission, #495 Diesel Engine, | ||
