parameters
4.1 Main performance
The feeding capacity of this machine is 2.8 kg/s. Performance of this machine shall meet the following table, there is no weed on cutter, the crops are straight up, crop/weed ratio of rice is 1.0~2.4, seed water content is 15~28%, stalk water content is 20~60%; crop/weed ratio of wheat is 0.8~1.2, seed water content is 10~20%, stalk water content is 10~25%.
Index Item | Rice | Wheat | |
Total loss rate (%) | £3.0 | £1.2 | |
Sundries content (%) | £2.0 | £2.0 | |
Broken rate (%) | £1.5 | £1.0 | |
Note: Operation efficiency and performance will come down if crop conditions exceed specified requirements.
4.2 Main technical parameters
NO. | Item | Unit | Specification |
1 | Structure |
| Track self-propelled full feeding |
2 | The range of the suitable crops(natural height) | mm | 550-1100 |
3 | Power equipped | Kw/rpm | 66/3200 |
4 | Pure working hour production rate | hm2/h | 0.37-0.60 |
5 | Fuel consumption per hectare | kg/hm2 | 18-25
|
6 | Size of figure during operation | mm | 4700×2400×2500
|
7 | Structural weight | kg | 2700
|
8 | Cutting width | mm | 2000 |
9 | Feeding quantity | t/h | 8.58
|
10 | clearance above the ground | mm | 260 |
11 | Turning type |
| hydraulic |
12 | Transmission
| step | HMCVT hydraulic stepless speed change device |
13 | Proceeding speed during operation | m/s | 0.5-1.3
|
14 | Cutter stroke | mm | ⅡModel |
15 | Harvester auger type |
| Telescopic vertical conveying screw |
16 | Harvester auger diameter | mm | F490
|
17 | Reel type |
| Eccentric teeth type |
18 | Reel diameter (mm) | mm | F900
|
19 | Reel rod number | piece | 5 |
20 | Convey belt type |
| chain raking type |
21 | Threshing drum type |
| Axle flow spike teeth type(double threshing drum) |
22 | Threshing drum size (diameter×length)(mm) | Small roller mm | F550×610
|
Big roller mm | F550×1064
| ||
23 | Concavity plate type |
| Grid type |
24 | Concavity plate angle | (°) | 220° |
25 | Fan type |
| Centrifugal fan |
26 | Fan diameter (mm) | mm | F330 |
27 | Grain discharge screw conveyor diameter ( mm) | mm | F160 |
28 | Grain discharge screw conveyer screw pitch (mm) | mm | 128
|
29 | The type of rethresher |
| Blade rotating
|
30 | Grain receiving method
|
| Mechanical self-unloading |
31 | Clearance between the harvester screw conveyor and the soleplate (mm) | mm | 13-15 |
32 | Rubber track (teeth number×pitch×width)(piece×mm×mm) | mm | 90mm×48joint×400mm 3sets in 40HQ container |
