Specifications
1. Basket in water.2. Operation part has adopted PLC or touch screen control system, this accords to customer's demand.
150L Gas Heating-type Plants Essential Oil Extraction Machine
| Model | EC10 | EC20 | EC30 | EC50 | EC100 | EC150 | EC200 | EC300 |
| Voltage | 10V | 20V | 30V | 50V | 100V | 150V | 200V | 300V |
| Power | 4.0KW | 4.5KW | 5.5KW | 9KW | 12KW | 14KW | 25KW | 25KW |
| Specifications |
1. Steam extraction part is popular with the structure of basket-in-water 3. This unit is automatically operate. 4. All kinds of plants can be the material of plants Essential Oil Extraction Machine on Sale. |
|||||||
1. Brief instruction of Plants Essential Oil Extraction Machine
Plants Essential Oil Extraction Machine is popular in production of Chinese medicines, health products, Biological drugs, cosmetics and food, it use technology of biological and chemical separation, can extract Plant components efficiently by steam distillation, have good effect in collecting essential oil from plants.
2. Special Design of Plants Essential Oil Extraction Machine
a. The steam extraction part of Plants Essential Oil Extraction Machine is popular with the structure of basket-in-water.
b. The operation part of our Plants Essential Oil Extraction Machine has adopted PLC or touch screen control system, this accords to customer’s demand.
3. Main Technical Datas of Plants Essential Oil Extraction Machine
a. Power: 4.0kw, 380v/50Hz, Three Phase
b. Volume of Distillation Pot: 150L
c. Heating Area of Extraction Tank: 1.45M2
d. Condensing Area of Condenser: 1.25M2
e. Cooling Area of Cooler: 1.20m2
f. Vacuum Pressure for Distillation: 0.3mpa
g. Moisture Extraction Temperature: 50~100c
h. Power Of Electric Heater: 4 kw (Includes Oil Heating System)
i. Cooling From Tap Water
4. Pictures of Plants Essential Oil Extraction Machine
200L Palnts Essential Oil Extraction Machine
Temperature Control Cabinet of Plants Essential Oil Extraction Machine
Detail of Plants Essential Oil Extraction Machine
More detail of Plants Essential Oil Extraction Machine
Oil-water Separator of Plants Essential Oil Extraction Machine
Plants Essential Oil Extraction Machine on Truck
Raw Material of Plants Essential Oil Extraction Machine
All kinds of plants can be the raw material of Plants Essential Oil Extraction Machine
Final Product of Plants Essential Oil Extraction Machine
5. Features of Plants Essential Oil Extraction Machine
a. By steam-distillation to reach the extraction of essential oils.
b. Easy operation. One person can operate the Plants Essential Oil Extraction Machine easily .
c. High efficiency. Using indirect heating of heat-transfer oil, it can quickly reach 100°C high temperature under the conditions of cleanness, safety and atmospheric pressure. If required, with vacuum pump, the extraction speed of essential oils will be more faster.
d. Compact structure. It covers only about 1.5 square meter.
e. Tank wall treated: inside mirror-polished, outside honed.
Any question about Plants Essential Oil Extraction Machine, please contact with us freely!
Thank you for interested in our Plants Essential Oil Extraction Machine!
