Specifications
1. Basket in water.2. Operation part has adopted PLC or touch screen control system, this accords to customer's demand.
150L Gas Heating-type Lavender Essential Oil Steam Distillation
| Model | EC10 | EC20 | EC30 | EC50 | EC100 | EC150 | EC200 | EC300 |
| Voltage | 10V | 20V | 30V | 50V | 100V | 150V | 200V | 300V |
| Power | 4.0KW | 4.5KW | 5.5KW | 9KW | 12KW | 14KW | 25KW | 25KW |
| Specifications |
1. Steam extraction part is popular with the structure of basket-in-water 3. This unit is automatically operate. 4. All kinds of plants can be the material of Lavender Essential Oil Steam Distillation on Sale. |
|||||||
1. Brief instruction of Lavender Essential Oil Steam Distillation
Lavender Essential Oil Steam Distillation is popular in production of Chinese medicines, health products, Biological drugs, cosmetics and food, it use technology of biological and chemical separation, can extract Plant components efficiently by steam distillation, have good effect in collecting essential oil from plants.
2. Special Design of Lavender Essential Oil Steam Distillation
a. Steam extraction part is popular with the structure of basket-in-water Lavender Essential Oil Steam Distillation.
b. Our Lavender Essential Oil Steam Distillation operation part has adopted PLC or touch screen control system, this accords to customer’s demand.
3. Main Technical Datas of Lavender Essential Oil Steam Distillation
a. Power: 4.0kw, 380v/50Hz, Three Phase
b. Volume of Distillation Pot: 150L
c. Heating Area of Extraction Tank: 1.45M2
d. Condensing Area of Condenser: 1.25M2
e. Cooling Area of Cooler: 1.20m2
f. Vacuum Pressure for Distillation: 0.3mpa
g. Moisture Extraction Temperature: 50~100c
h. Power Of Electric Heater: 4 kw (Includes Oil Heating System)
i. Cooling From Tap Water
4. Pictures of Lavender Essential Oil Steam Distillation
200L Lavender Essential Oil Steam Distillation
Temperature Control Cabinet of Lavender Essential Oil Steam Distillation
Detail of Lavender Essential Oil Steam Distillation
More detail of Lavender Essential Oil Steam Distillation
Oil-water Separator of Lavender Essential Oil Steam Distillation
Lavender Essential Oil Steam Distillation on Truck
Raw Material of Lavender Essential Oil Steam Distillation
All kinds of plants can be the raw material of Lavender Essential Oil Steam Distillation
Final Product of Lavender Essential Oil Steam Distillation
5. Features of Lavender Essential Oil Steam Distillation
a. By steam-distillation to reach the extraction of essential oils.
b. Easy operation. One person can operate the Lavender Essential Oil Steam Distillation easily .
c. High efficiency. Using indirect heating of heat-transfer oil, it can quickly reach 100°C high temperature under the conditions of cleanness, safety and atmospheric pressure. If required, with vacuum pump, the extraction speed of essential oils will be more faster.
d. Compact structure. It covers only about 1.5 square meter.
e. Tank wall treated: inside mirror-polished, outside honed.
Any question about Lavender Essential Oil Steam Distillation, please contact with us freely!
Thank you for interested in our Lavender Essential Oil Steam Distillation!
