Specifications
1. Basket in water.2. Operation part has adopted PLC or touch screen control system, this accords to customer's demand.
150L Gas Heating-type Pure Essential Oil Steam Distillation
| Model | EC10 | EC20 | EC30 | EC50 | EC100 | EC150 | EC200 | EC300 |
| Voltage | 10V | 20V | 30V | 50V | 100V | 150V | 200V | 300V |
| Power | 4.0KW | 4.5KW | 5.5KW | 9KW | 12KW | 14KW | 25KW | 25KW |
| Specifications |
1. Steam extraction part is popular with the structure of basket-in-water 3. This unit is automatically operate. 4. All kinds of plants can be the material of Sage Essential Oil Steam Distillation on Sale. |
|||||||
1. Brief instruction of Sage Essential Oil Steam Distillation
Sage Essential Oil Steam Distillation is popular in production of Chinese medicines, health products, Biological drugs, cosmetics and food, it use technology of biological and chemical separation, can extract Plant components efficiently by steam distillation, have good effect in collecting essential oil from plants.
2. Special Design of Sage Essential Oil Steam Distillation
a. Steam extraction part of Sage Essential Oil Steam Distillation is popular with the structure of basket-in-water .
b. Our Sage Essential Oil Steam Distillation operation part has adopted PLC or touch screen control system, this accords to customer’s demand.
3. Main Technical Datas of Sage Essential Oil Steam Distillation
a. Power: 4.0kw, 380v/50Hz, Three Phase
b. Volume of Distillation Pot: 150L
c. Heating Area of Extraction Tank: 1.45M2
d. Condensing Area of Condenser: 1.25M2
e. Cooling Area of Cooler: 1.20m2
f. Vacuum Pressure for Distillation: 0.3mpa
g. Moisture Extraction Temperature: 50~100c
h. Power Of Electric Heater: 4 kw (Includes Oil Heating System)
i. Cooling From Tap Water
4. Pictures of Sage Essential Oil Steam Distillation
200L Sage Essential Oil Steam Distillation
Temperature Control Cabinet of Sage Essential Oil Steam Distillation
Detail of Sage Essential Oil Steam Distillation
More detail of Sage Essential Oil Steam Distillation
Oil-water Separator of Sage Essential Oil Steam Distillation
Sage Essential Oil Steam Distillation on Truck
Raw Material of Sage Essential Oil Steam Distillation
All kinds of plants can be the raw material of Sage Essential Oil Steam Distillation
Final Product of Sage Essential Oil Steam Distillation
5. Features of SageEssential Oil Steam Distillation
a. By steam-distillation to reach the extraction of essential oils.
b. Easy operation. One people can operate the Sage Essential Oil Steam Distillation easily .
c. High efficiency. Using indirect heating of heat-transfer oil, it can quickly reach 100°C high temperature under the conditions of cleanness, safety and atmospheric pressure. If required, with vacuum pump, the extraction speed of essential oils will be more faster.
d. Compact structure. It covers only about 1.5 square meter.
e. Tank wall treated: inside mirror-polished, outside honed.
Any question about Sage Essential Oil Steam Distillation, please contact with us freely!
Thank you for interested in our Sage Essential Oil Steam Distillation!
