Help Center200L Effective Lemon Essential Oil Extractor on Sale (EC)
Related Products
-
100L Pure Essential Oil Extractor on SaleUS$ 13,276 - 13,940MOQ: 1 Set -
150L High Quality Plants Essential Oil Distillation Macine on SaleUS$ 15,207 - 15,967MOQ: 1 Set
-
150L High Quality Chamomile Essential Oil Distillation Machine on SaleUS$ 15,207 - 15,967MOQ: 1 Set
-
100L Automatic Tea Tree Essential Oil Making MachineUS$ 13,276 - 13,940MOQ: 1 Set
-
100L Automatic Lavender Oil Extraction MachineUS$ 13,276 - 13,940MOQ: 1 Set
Specifications
1. Basket in water.2. Operation part has adopted PLC or touch screen control system, this accords to customer's demand.
| Model | EC10 | EC20 | EC30 | EC50 | EC100 | EC150 | EC200 | EC300 |
| Voltage | 10V | 20V | 30V | 50V | 100V | 150V | 200V | 300V |
| Power | 4.0KW | 4.5KW | 5.5KW | 9KW | 12KW | 14KW | 25KW | 25KW |
| Specifications |
1. Steam extraction part is popular with the structure of basket-in-water 3. This unit is automatically operate. 4. All kinds of plants can be the material of Lemon Essential Oil Extractor. |
|||||||
1. Brief instruction of Lemon Essential Oil Extractor
Lemon Essential Oil Extractor is popular in production of Chinese medicines, health products, Biological drugs, cosmetics and food, it use technology of biological and chemical separation, can extract Plant components efficiently by steam distillation, have good effect in collecting essential oil from plants.
2. Special Design of Lemon Essential Oil Extractor
a. Steam extraction part is popular with the structure of basket-in-water Lemon Essential Oil Extractor.
b. Our Lemon Essential Oil Extractor operation part has adopted PLC or touch screen control system, this accords to customer’s demand.
3. Main Technical Datas of Lemon Essential Oil Extractor
a. Power: 25.0kw, 380v/50Hz, Three Phase
b. Volume of Distillation Pot: 200L
c. Heating Area of Extraction Tank: 1.85M2
d. Condensing Area of Condenser: 1.50M2
e. Cooling Area of Cooler: 1.65m2
f. Vacuum Pressure for Distillation: 0.3mpa
g. Moisture Extraction Temperature:80~200c
h. Power Of Electric Heater: 25kw (Includes Oil Heating System)
i. Cooling From Tap Water
4. Pictures of Lemon Essential Oil Extractor
200L Lemon Essential Oil Extractor
Temperature Control Cabinet of Lemon Essential Oil Extractor
Detail of Lemon Essential Oil Extractor
More detail of Lemon Essential Oil Extractor
Lemon Essential Oil Extractor Loaded on The Car
Raw Material of Lemon Essential Oil Extractor
All kinds of plants can be the raw material of Lemon Essential Oil Extractor
Final Product of Lemon Essential Oil Extractor
5. Features of Lemon Essential Oil Extractor
a. By steam-distillation to reach the extraction of essential oils.
b. Easy operation. One people can operate this Lemon Essential Oil Extractor easily.
c. High efficiency. Using indirect heating of heat-transfer oil, it can quickly reach 100°C high temperature under the conditions of cleanness, safety and atmospheric pressure. If required, with vacuum pump, the extraction speed of essential oils will be more faster.
d. Compact structure. It covers only about 1.5 square meter.
e. Tank wall treated: inside mirror-polished, outside honed.
Any question about Lemon Essential Oil Extractor, please contact with us freely!
Thank you for interested in our Lemon Essential Oil Extractor!
