Aluminum Injecting Hydraulic Press, Aluminum Forming Machine

Aluminum Injecting Hydraulic Press, Aluminum Forming Machine thumbnail-1
Aluminum Injecting Hydraulic Press, Aluminum Forming Machine photo-1
US$ 8,300 - 10,300 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Shengli
Model Number:
HJ013
Contact Supplier Request Quote Chat Now
Huzhou Machine Tool Works Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Shengli
Model Number HJ013
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.injecting aluminum liquid into the motor rotor
2.a PLC control
3.three operating modes of inch

It is specially designed for injecting aluminum liquid into the motor rotor, a PLC control, three operating modes of inch, manual and semi-automatic, one-by-one execute actions of slow, quick injecting, pressurizing and cutting off the pouring head. It's especially available for injecting Y-type motor rotors and similar motor rotors. The 400KN model mainly for injecting micro-motor rotors of fans and laundry machines without actions of three-step injecting and pouring head cut off. It is loaded with guard barriers to prevent the operator from burnt injury. Nominal capacity: 400-10000KN Iron core: D50-D600mm



Item Unit HJ013-40 HJ013A-100 HJ013-200 HJ013-315 HJ013-500 HJ013-630
Motor Rotor Range   Micro-motor Y80~Y160 Y160~Y280 Y200~Y355 Y280~Y500-4 400~600
Nominal Close-die Force KN 400 1000 2000 3150 5000 6300
Injecting Force KN 100 380 560 800 2000 1500
Pressurizing KN / 600 900 1140 3150 3000
Cut-off Force KN / 95 300 370 1000 1250
Working Pressure Mpa 28 25 25 25 25 25
Ram Stroke mm 320 600 580 800 900 1000
Injecting Stroke mm 150 200 250 400 500 650
Daylight mm 520 750 900 1150 1500 1800
Aluminum Liquid Amount kg / 6 19 60 150 200
Ram Speed Quick Descent mm/s 65 100 100 80 120 150
Slow Descent 10 16 16 10 10 10
Return 105 100 80 60 100 100
Injecting Speed Slow mm/s 155 38 65 45 45 55
Quick 600 1000 1000 1000 1000 2000
Return 405 100 160 120 100 100
Opening Table Size LR mm 460 710 900 1120 1380 1500
FB 400 630 900 1120 1400 1500
Overall Size FB mm 1600 1650 4600 4730 5518 6445
LR 1750 2480 3100 3800 5445 7035
Height above Floor 2480 3855 4450 5410/4110 5018 5512
Motor power kw 5.5 11 15 18.5 74 74
