Application & Feature
It is specially designed for injecting aluminum liquid into the motor rotor, a PLC control, three operating modes of inch, manual and semi-automatic, one-by-one execute actions of slow, quick injecting, pressurizing and cutting off the pouring head. It's especially available for injecting Y-type motor rotors and similar motor rotors. The 400KN model mainly for injecting micro-motor rotors of fans and laundry machines without actions of three-step injecting and pouring head cut off.
It is loaded with guard barriers to prevent the operator from burnt injury.
Nominal capacity: 400 ~ 10000 KN
Iron core: Φ50 ~ Φ600mm
Main Technical Data
| Item | Unit | HJ013-40 | HJ013A-100 | HJ013-200 | HJ013-315 | HJ013-500 | HJ013-630 | |
| Motor Rotor Range | Micro-motor | Y80~Y160 | Y160~Y280 | Y200~Y355 | Y280~Y500-4 | 400~600 | ||
| Nominal Close-die Force | KN | 400 | 1000 | 2000 | 3150 | 5000 | 6300 | |
| Injecting Force | KN | 100 | 380 | 560 | 800 | 2000 | 1500 | |
| Pressurizing | KN | / | 600 | 900 | 1140 | 3150 | 3000 | |
| Cut-off Force | KN | / | 95 | 300 | 370 | 1000 | 1250 | |
| Working Pressure | Mpa | 28 | 25 | 25 | 25 | 25 | 25 | |
| Ram Stroke | mm | 320 | 600 | 580 | 800 | 900 | 1000 | |
| Injecting Stroke | mm | 150 | 200 | 250 | 400 | 500 | 650 | |
| Daylight | mm | 520 | 750 | 900 | 1150 | 1500 | 1800 | |
| Aluminum Liquid Amount | kg | / | 6 | 19 | 60 | 150 | 200 | |
| Ram Speed | Quick Descent | mm/s | 65 | 100 | 100 | 80 | 120 | 150 |
| Slow Descent | 10 | 16 | 16 | 10 | 10 | 10 | ||
| Return | 105 | 100 | 80 | 60 | 100 | 100 | ||
| Injecting Speed | Slow | mm/s | 155 | 38 | 65 | 45 | 45 | 55 |
| Quick | 600 | 1000 | 1000 | 1000 | 1000 | 2000 | ||
| Return | 405 | 100 | 160 | 120 | 100 | 100 | ||
| Opening Table Size | LR | mm | 460 | 710 | 900 | 1120 | 1380 | 1500 |
| FB | 400 | 630 | 900 | 1120 | 1400 | 1500 | ||
| Overall Size | FB | mm | 1600 | 1650 | 4600 | 4730 | 5518 | 6445 |
| LR | 1750 | 2480 | 3100 | 3800 | 5445 | 7035 | ||
| Height above Floor | 2480 | 3855 | 4450 | 5410/4110 | 5018 | 5512 | ||
| Motor power | kw | 5.5 | 11 | 15 | 18.5 | 74 | 74 | |
1.Specifications mentioned above are subject to any change without notice.
2.The products can be tailored as customer's desire or provide a full set for electric motor manufacture.
FAQ ABOUT HYDRAULIC PRESSES
Does welded beam easy deformation?
We treat it with tempering treatment to reduce internal stress.Besides, we also make casting beam.
The oil cylinder is important part,what if it broke?
We use forging cylinder which is forged by one 45# round steel,no welded.The broke rate is almost zero.
What about the electric system?
We use PLC electric control system with less line,easy maintenance and can programmable.
If part of the machine broke,does it easier to buy it in our country?
We can use customer appointed accessories if necessary.
Do you provide after service?
We provide technical service for life.
we are manufacturer of hydraulic press more than fifty years and can manufacture non-standard hydraulic press as your need( such as large worktable,deep slider stroke,multiple cylinder,high speed,double acting...)
