Home > Products > New Products > High income hengchuan discharge by rubber belt for sale
High income hengchuan discharge by rubber belt for sale
- 30 Unit / Units per Month
- qingdao
- T/T
- The new custom Hengchuan Magnetic Separator
- Gold dredger,Gold Dredger for sale,Bucket Wheel Type Gold Dredger
- Bucket Wheel Sand Washing Machinery/Energy Saving Sand Washer/Spiral Sand Washer
- Wheel Sand Washing and Processing Machine, Construction Sand Making Machine For Sale
- China Price Wheel Type Sand Washing Machine For Sale
- Portable Sand Washing Plant Wheel Sand Washing Machine For Sale
Product Details
Brand: | hengchuan | Model: | HCG |
Packaging Details
Contract packaging listed
Product Description
Magnetic Separation
Company profile
Shandong Hengchuan Ore Machinery Co. , Ltd, established in 2002, is leading ore machinery in china. Company covers area of 20000 square meters.
Our main products :Placer Gold Mining Machine ,Magnetic Separator ,Sand Mining and Washing Machine, Mining Dredgers ,Sand Barges, Particular Vessels, etc. They have been sold not in domestic market, but export to more than thirty foreign countries, like Philippines, Malaysia, North Korea , Mongolia, Cameroon, South Africa, Ghana, Brazil, etc.
Strong Magnetic Force Separator
Short Introduction
1 Strong magnetic separator is designed with advanced technology . The magnetic force can get 1000-22000GS
2 Discharging usually by hairbrush and rubber belt
3 This machine applys to Manganese Mine , Hematite Mine , Limonte Mine , Quartz Mine ,kaolin Mine , Potassium Feldspar ,etc.
4 Have exported to lran , korea , Indonesia and many other countries .
Short Introduction
Yype | Capacity T/h | Power | Magnetic strength GS | Magnetic separator type mm |
HCQ-100 | 1-3 | 1-3 | 12000-14500 | 100*1000 |
HCQ-150 | 3-5 | 3-5.5 | 12000-14500 | 150*1200 |
HCQ-220 | 5-10 | 5.5-7.5 | 12000-14500 | 220*1500 |
HCQ-380 | 10-20 | 5.5-11 | 12000-14500 | 380*2000 |
Discharge by rubber belt
Working principle
The material through the feed funnel to belt feeder belt surface, with the rotation AC adjustable speed motor, belt is moving ahead slowly, with a surface material through the first round to enter the next process, to achieve continuous feeding.
The product structure
Belt conveyer is mainly composed of a machine frame, a conveyer belt, a belt roller,tensioning device, transmission device, etc.. The fuselage uses the high quality steel plate connected, by the high and low around the leg of the difference form the frame, the plane is provided with a certain inclined angle. The machine frame is provided with a roller, roller,used for driving and supporting conveyor belt. A deceleration motor drive and electric drive roller in two ways.
Company qualification
Contact Us
Name | Yellow Science Yellow |
Website | www.hcchina.en.china.cn |
Company Name | Shandong Hengchuan Ore Machinery Co.;Ltd |
Address | Mihe Industrial zone,Qingzhou City,Shandong province |
Company Profile
Qingzhou Hengchuan Ore Machinery Co.,ltd,was established in 2002,a leading ore machinery manufacturer in China,covering an area of 20000 square meters,have 6 engineers,20 technicians and 100 workers.
Our main products:Gold Mining Machinery,Magnetic separators and all kinds of mining dredger etc.Our main market is domestic,Africa and Southeast Asia,such as Cameroon,Ghana,Mali,Zimbabwe,Malaysia,Indonesia and Philippines etc.
Cutter suction dredger is widely used in dredging engineering.The rotating cutting head in the front of the suction pipe can stir slurry,then dredging pump suck the slurry through the suction pipe,then through the discharge pipe to the mud yards.Dredging, transportation and discharge is a whole series work.So the cutter suction dredger is an efficient and economic dredger.We start to manufacture the cutter suction dredger from 2005,gradually accumulated rich experience in this field.
Development History:
A).Established Magnet Research Institute in 2004,successfully developed the high gradient magnetic separator to 12000-22000GS.
B).Cooperated with Shandong Gold Group and doubled the sales scale.
C).Developed STL-120 gold centrifugal concentrator in 2008.
D).Mature dredger products in 2009.
E).Developed successfylly knelson smiliar type automatic discharge type gold centrifual concentrtor and produced them in large quantity for sellling.
F).Established Shandong Hengchuan International Trade Co.,Ltd in 2015.
Enterprise Spirit -eternal integrity
Enterprise Purpose-to consistently exceed customers' expectations
Core Values-innovation and leading the future
Service Concept- to create value for customers
Development Concept - Quality is life; innovation is the driving force
Corporate Vision- the world leading supplier of magnetic separation equipment
