OEM/ODM Customized China Supplier Gold Jig Concentrator for Sale
- 100 Unit / Units per Month
- qingdao
- T/T
You May Like
-
China Supplier Latest Technology Small Scale Ball Clay Grinding Mill for Sale
-
OEM/ODM Customized China Supplier Jigging Machine for Gold ,Diamond and Ruby
-
China Supplier Latest Technology Small Gold Ball Mill for Rock Gold Ore Grinding
-
China Supplier Latest Technology Small Scale Mineral Rotary Ball Mill for Rock Gold Ore Processing
-
OEM/ODM Customized China Supplier Energy Saving Gold Concentrator Jig Machine,Diamond Jigger
-
China Supplier Latest Technology Gold Mining Ball Mill for Hematite, Iron Ore, Copper Ore, Dolomite, Bentonite, Limest
Product Details
| Condition | New | Type | Gravity Separator | |
| Production Capacity | 5-10Tons per hour | Place of Origin | Shandong, China | |
| Brand Name | HENGCHUAN | Model Number | HCJT2-2 | |
| Voltage | 380V/50HZ | Power(W) | 3kw | |
| Dimension(L*W*H) | 3225*1550*2050mm | Weight | 1640kg | |
| Certification | ISO | Warranty | 1 yeat | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Standard containers, bare main machine, motors and small parts are packed in wooden box.
Product Description
OEM/ODM Customized China Supplier Gold Jig Concentrator for Sale
1. Application of OEM/ODM Customized China Supplier Gold Jig Concentrator for Sale
Alluvial Gold Jigger/Jigger Machine/Jigging Machine is kind gravity jig separator for gold and other mineral materalis concentration. It can be widely used to select Tungsten, tin, gold, red iron, brown iron, manganese, titanium, antimony, lead, tantalum, niobium, placer gold, alluvial gold and other minerals.Due to its high processing capacity, large range of separation size and simplicity of operation and maintenance.
In practice, contrast of Saw-tooth Wave Jig and Sine Wave Jig shows up raises of recovery of Saw-tooth Wave Jig: Sn:3.01%, W:5.5%, Pb:1.63%, Zn:2.04%.
2. Working Principle of OEM/ODM Customized China Supplier Gold Jig Concentrator for Sale
Alluvial Gold Jigger/Jigger Machine/Jigging Machine is one way of gravity concentration. It belongs to deep trough concentration operation (gravity equipment), using water as processing media, it depends on the difference of specific gravity between the minerals select and gangue to separate mine,the stroke and time of stroke is adjustable depend on different specific gravity of minerals. It is special for tin ore, manganese ore, coal, placer gold, alluvial gold concentration.
3.Advantages and Characteristics of OEM/ODM Customized China Supplier Gold Jig Concentrator for Sale
1). High capacity
2).High concentration ratio and high recovery
3). Easy to install, operate and maintain
4). The pulsation curve is saw-tooth wave shape facilitate heavy mineral to settling
5).Saving water 30-40% than ordinary jig
6). The pulsation speed very easy adjusted by regulator
7). Can achieve a good result in processing such as placer gold, tungsten,iron, tin, hematite, copper, tantalum-niobium, titanium, manganese, barite, zirconium, chrome and gemstone etc.
4.Main Technical Parameters of OEM/ODM Customized China Supplier Gold Jig Concentrator for Sale
Model | Hutch | Feeding Size (mm) | Makeup water (m3/t) | Makeup water pressure (Mpa) | Capacity (t/h) | Power (kw) | Dimensions (mm) | Weight (Kg) | |
Shape | Area (m2) | ||||||||
JT0.57-1 | Trapezoid | 0.57 | <6 | 1-2 | ≥0.05 | 1.5-3 | 1.5 | 1550×780×1530 | 610 |
JT1-1 | Trapezoid | 1.04 | <10 | 2-3 | 2.5-5 | 2.2 | 2270×1110×1890 | 900 | |
JT2-2 | Rectangle | 2.28 | <10 | 2-4 | 5-10 | 3 | 3225×1550×2050 | 1640 | |
JT3-1 | Trapezoid | 3 | <10 | 3-6 | 7.5-15 | 5.5 | 2745×2000×3030 | 3085 | |
JT4-2 | Rectangle | 4 | <25 | 4-8 | 8-20 | 7.5 | 4240×1990×2750 | 3098 | |
JT4-2S | Rectangle | 4 | <25 | 4-8 | 8-20 | 4×2 | 4240×1990×2750 | 3500 | |
JT5-2 | Trapezoid | 4.86 | <10 | 3-6 | 12-25 | 7.5 | 3600×2000×2600 | 45 | |
5. OEM/ODM Customized China Supplier Gold Jig Concentrator for Sale Products Show
5.Shipping of OEM/ODM Customized China Supplier Gold Jig Concentrator for Sale
6.Working Site of OEM/ODM Customized China Supplier Gold Jig Concentrator for Sale
