China Supplier Black Gold Magnetic Separator Machine for Sale

Name: China Supplier Black Gold Magnetic Separator Machine for Sale
Brand: Hengchuan
Availability: InStock

FOB Price

USD $3,000 - $100,000 / Set

1 Set(Min.Order)

Supply Ability 30 Set / Sets per Month
Port qingdao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Magnetic Separator
Production Capacity	90%	Place of Origin	Shandong, China
Brand Name	Hengchuan	Model Number	HCGP-1020
Voltage	380V	Power(W)	1.5--4KW
Dimension(LWH)	3&2&2m	Weight	0.8T--5T
Certification	ISO9001	Warranty	one year
After-sales Service Provided	Engineers available to service machinery overseas

Packaging Details

The contract shall prevail

Product Description

China Supplier Black Gold Magnetic Separator Machine for Sale

1.Introduction of China Supplier Black Gold Magnetic Separator Machine for Sale

High gradient plate permanent magnetic separator is a newly developed product which combines physical mechanics with fluid mechanics and magneto mechanics.All the magnetic materials adopt rare earth neodymium iron boron,and the highest magnetic filed intensity can reach 15000 Gauss.This product is applicable to iron separation and purification of non-metallic ore in wet process,especially for quartz,feldspar, nepheline ore and kaolinite.It can also be used for the wet separation of hematite, limonite,siderite ore,manganese ore,chromite,ilmenite,wolframite and other weak magnetic metallic ore.

2.Features of China Supplier Black Gold Magnetic Separator Machine for Sale

1. High magnetic filed gradient and intensity.

2. Large separation area.

3. The belt speed is adjustable.

4. Lower cost compared to vertical ring magnetic separator.

5. Stable performance and long service life.

3.Diagram of China Supplier Black Gold Magnetic Separator Machine for Sale

4.Parameter of China Supplier Black Gold Magnetic Separator Machine for Sale

ITEM	SIZE OF MAGNETIC SEPRATION ZONE	CAPACITY	MAGNETIC INTENSITY	FEEDING CONCENTRATION %	SEPARATION SIZE	POWER
HCGP-1020	1000*2000	10-15t/h	15000gs	20-25	≤5mm	1.5kw
HCGP-2025	2000×2500	25-30t/h	15000gs	20-25	≤5mm	3kw
HCGP-2530	2500×3000	35-40t/h	15000gs	20-25	≤5mm	4kw

5.Products Show of China Supplier Black Gold Magnetic Separator Machine for Sale

6.Shipping of China Supplier Black Gold Magnetic Separator Machine for Sale
