Benefination Clay Mine Rotary Scrubber
- QINGDAO
You May Like
-
Thickening Type Steel Plate Clay Gold Washing Plant for Sand Gold
-
China Best Selling Heavy Clay Gold Wash Plant
-
Mini Portable Gold Sand Washing Machine for Korea Small Gold Mine
-
Gold Mining Equipment/Gold Trommel Washing Plant/Gold Sluice For Sale
-
High Recovery Gold Mining Concentrate Machine With CE Certificate In Qingzhou
-
Generator Power Small Rotary Drum Sieve For Sale
Product Details
| Condition | New | Type | Gravity Separator | |
| Production Capacity | 5-200/h | Place of Origin | Shandong, China | |
| Brand Name | HENGCHUAN | Model Number | HCM-200 | |
| Voltage | 220/380V | Power(W) | 4-100kw,can be customized | |
| Dimension(L*W*H) | 10m*2m*2.4m,can be customized | Weight | 1.2T,can be customized | |
| Certification | CE certificate and ISO9000 | Warranty | one year warranty except the quick wear parts | |
| After-sales Service Provided | Engineers available to service machinery overseas |
7 days after receive the payment
Product Description
Specifications
clay mine rotary scrubber1.Includes the washing function and separating function
2.The size and capacity can be customized
Benefination Clay Mine Rotary Scrubber
Clay is every miner's enemy no matter what type machine you use. Clay will cut production down significantly, and results will vary depending on your clay content.
1. Working principle of Benefination Clay Mine Rotary Scrubber
Excavator Load Raw Material to Plant Hopper Feeder Bin with grizzly—>Rotary Scrubber—>Trommel Screen—>Pulsating Sluice —>Concentrator—>Shaking Table—> Amalgamator —> Mercury Distiller—>Gold Furnace
1). Feeding material by excavator to Grizzl Feeder, The grizzly on the hopper will first separate the big stones.
2). Then the wanted raw ore fed into the Trommel Scrubber.
Our specially designed Gold Trommel Scrubber Washing Plant consists of Rotary Scrubber for washing clay and Trommel Screen for sieving different size of ore.
Material is scrubbed and clays and silts dispersed into slurry.The clay and ore will be separated.
The Trommel Screen will further separate different size ores, the ore bigger than screen mesh can be separated and dischaged out by the conveyor.
Can be make mobile type or stationary type.
The length &diameter of drum unit, screen mesh, layer quantity of screen can be customized.
3). The small ores will go to the Auto Washing Belt.
This Auto Washing Belt is variable frequency speed control system. Mineral travels against the running direction of auto washing belt ,so can keep the ore loose. The gold will sink down in the bottom,lighter particles will flow away by water.
4). Tailings from Auto Washing Belt are directed to the Gold Centrifugal Concentrator,where fine gold will be recovered.
5) Collect the concentration from Centrifuge and Sluice Machine,Use shaking table for further concentrating.
6). If need pure gold particles or dust,then need equip the Amalgamator and Mercury Distiller removal of impurities after shaking table.
7). If need melt the gold dust to gold bar,then can equip with a Gold Melting Furnace.
2. Benefination Clay Mine Rotary Scrubber Products Show:
Fast contact way :
Company Profile
Qingzhou Hengchuan Ore Machinery Co.,ltd,was established in 2002,a leading ore machinery manufacturer in China,covering an area of 20000 square meters,have 6 engineers,20 technicians and 100 workers. Our main products:Gold Mining Machinery,Magnetic separators and all kinds of mining dredger etc.Our main market is domestic,Africa and Southeast Asia,such as Cameroon,Ghana,Mali,Zimbabwe,Malaysia,Indonesia and Philippines etc. Cutter suction dredger is widely used in dredging engineering.The rotating cutting head in the front of the suction pipe can stir slurry,then dredging pump suck the slurry through the suction pipe,then through the discharge pipe to the mud yards.Dredging, transportation and discharge is a whole series work.So the cutter suction dredger is an efficient and economic dredger.We start to manufacture the cutter suction dredger from 2005,gradually accumulated rich experience in this field. Development History: A).Established Magnet Research Institute in 2004,successfully developed the high gradient magnetic separator to 12000-22000GS. B).Cooperated with Shandong Gold Group and doubled the sales scale. C).Developed STL-120 gold centrifugal concentrator in 2008. D).Mature dredger products in 2009. E).Developed successfylly knelson smiliar type automatic discharge type gold centrifual concentrtor and produced them in large quantity for sellling. F).Established Shandong Hengchuan International Trade Co.,Ltd in 2015. Enterprise Spirit -eternal integrity Enterprise Purpose-to consistently exceed customers' expectations Core Values-innovation and leading the future Service Concept- to create value for customers Development Concept - Quality is life; innovation is the driving force Corporate Vision- the world leading supplier of magnetic separation equipment
