Specifications
ZOOMLION Rough Terrain Crane RT351Max.rated lifting load: 35T
2Full-extend boom lifting height: 34m
3Engine:CUMMINS
ZOOMLION Rough Terrain Crane RT35
1.Max.total rated lifting load: 35T
2.Full-extend boom lifting height: 34m
3.Engine:CUMMINS
Item Unit Parameters
Max.rated lifting capacity * kg.m 35000×3.0
Max.load moment for basic boom kN.m 1340
Max.load moment for fully extended boom kN.m 902
Max.lifting height for basic boom m 34
Max.lifting height for jib m 48.5
Overall dimension (L*W* H) mm 11840×2980×3600
Outrigger span(longitudinal/ lateral) mm 6810×6800
Boom length mm 9800~31000
Jib length mm 9088~15028
Boom angle ° -3~78
Slewing range 360° continuous
Max.main winch speed m/min 150
Boom telescoping time(extending) s 70
Boom telescoping time(retracting) s 75
Boom raising time s 46
Boom lowering time s 47
Slewing speed r/min 0~2.5
Rated working pressure MPa 27
Rated working flow L/min 400
Hydraulic tank capacity L 600
Machine weight kg 32000
Front axle load kg 15060
Rear axle road kg 16910
Max.travel speed(forward/backward) km/h 38/15
Wheelbase mm 3820 Wheelbase(front/rear) mm 2444
Max. Grade-ability % 110
Min.turning radius m 6.5
