Hot Sale 55Ton ZOOMLION Rough Terrain Crane RT550

Name: Hot Sale 55Ton ZOOMLION Rough Terrain Crane RT550
Brand: Zoomlion
SKU: 141326462
Availability: InStock

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Application:

all construction

Rated Loading Capacity:

35t

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application all construction

Rated Loading Capacity 35t

Rated Lifting Moment 3500Kn.m

Max. Lifting Load 35t

Place of Origin Hunan, China

Brand Name Zoomlion

Model Number RT35

Certification BV, ISO

Warranty 30days

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Rough Terrain Crane RT550
1.Max.loading:55t
2 Engine:CUMMINS 160KW
3.Max.lifting height:56.4m
4.Kessler axle, 4x4 drive

55Ton Rough Terrain Crane ZOOMLION RT550

Features:

1.Max.loading:55t
2 Engine:CUMMINS 160KW

Type	Ser. No.	Item	Unit	Value
Working performance	1	Max. rated lifting weight × working radius	kg.m	55000×3.0
	2	Max. lifting moment of basic boom	kN.m	1967
	3	Max.lifting moment of longest boom	kN.m	1126
	4	Max. lifting height of longest boom	m	34.8
	5	Max. lifting height of jib	m	52.4
Dimensions	6	Outline dimensions (L×W×H)	mm	13100×3300×3750
	7	Distance between outriggers (Longitudinal × transversal)	mm	6900×6900
	8	Main boom length (completely retracted – completely extended)	mm	10800~34000
	9	Jib length (completely retracted – completely extended)	mm	10000~17000
	10	Main boom angle of elevation	°	-3~78
	11	Swing range		360°continuously
Working speed	12	Max.speed of single rope on the drum of main winch	m/min	150
	13	Boom extension time	s	100
	14	Boom retraction time	s	80
	15	Boom derricking up time	s	56
	16	Boom derricking down time	s	63
	17	Swing speed	r/min	0~2.5
Hydraulic system	18	Rated working pressure	MPa	27
	19	Rated working flow	L/min	400
	20	Hydraulic oil tank capacity	L	700
Mass	21	Complete vehicle kerb mass	kg	39200
	22	Front axle load	kg	20440
	23	Rear axle load	kg	18760
Traveling	24	Max. traveling speed (forwards / backwards)	km/h	39/15
	25	Wheelbase	mm	3950
	26	Treads (front / rear)	mm	2605
	27	Max. gradeability	%	75
