Specifications
Rough Terrain Crane RT5501.Max.loading:55t
2 Engine:CUMMINS 160KW
3.Max.lifting height:56.4m
4.Kessler axle, 4x4 drive
55Ton Rough Terrain Crane ZOOMLION RT550
Features:
1.Max.loading:55t
2 Engine:CUMMINS 160KW
3.Max.lifting height:56.4m
4.Kessler axle
5.4*4 drive
6.Crab steering,2 wheel steering,4 wheel steering
7.Wheel base 3950 mm,allowing convenient steering in narrow space
The machine adpot four wheel drive and four wheel steering, so the machine have three kind moving control, two wheel steering, four wheel steering and crabbing.
Short wheelbase design make the machine very convinient in narrow space, minimum turning diameter.
Parameters:
Type |
Ser. No. |
Item |
Unit |
Value |
Working performance |
1 |
Max. rated lifting weight × working radius |
kg.m |
55000×3.0 |
2 |
Max. lifting moment of basic boom |
kN.m |
1967 |
|
3 |
Max.lifting moment of longest boom |
kN.m |
1126 |
|
4 |
Max. lifting height of longest boom |
m |
34.8 |
|
5 |
Max. lifting height of jib |
m |
52.4 |
|
Dimensions |
6 |
Outline dimensions (L×W×H) |
mm |
13100×3300×3750 |
7 |
Distance between outriggers (Longitudinal × transversal) |
mm |
6900×6900 |
|
8 |
Main boom length (completely retracted – completely extended) |
mm |
10800~34000 |
|
9 |
Jib length (completely retracted – completely extended) |
mm |
10000~17000 |
|
10 |
Main boom angle of elevation |
° |
-3~78 |
|
11 |
Swing range |
|
360°continuously |
|
Working speed |
12 |
Max.speed of single rope on the drum of main winch |
m/min |
150 |
13 |
Boom extension time |
s |
100 |
|
14 |
Boom retraction time |
s |
80 |
|
15 |
Boom derricking up time |
s |
56 |
|
16 |
Boom derricking down time |
s |
63 |
|
17 |
Swing speed |
r/min |
0~2.5 |
|
Hydraulic system |
18 |
Rated working pressure |
MPa |
27 |
19 |
Rated working flow |
L/min |
400 |
|
20 |
Hydraulic oil tank capacity |
L |
700 |
|
Mass |
21 |
Complete vehicle kerb mass |
kg |
39200 |
22 |
Front axle load |
kg |
20440 |
|
23 |
Rear axle load |
kg |
18760 |
|
Traveling |
24 |
Max. traveling speed (forwards / backwards) |
km/h |
39/15 |
25 |
Wheelbase |
mm |
3950 |
|
26 |
Treads (front / rear) |
mm |
2605 |
|
27 |
Max. gradeability |
% |
75 |
