Tower Crane--topkit TC6018/QTZ160--CANMAX

Name: Tower Crane--topkit TC6018/QTZ160--CANMAX
Brand: CANMAX
SKU: 141326086
Availability: InStock

US$ 28,000 - 90,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

construction

Rated Loading Capacity:

10t

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application construction

Rated Loading Capacity 10t

Rated Lifting Moment 1250KN.m

Max. Lifting Load 10t

Max. Lifting Height 160m

Span 60m

Place of Origin Shanghai, China

Brand Name CANMAX

Model Number TC6518/QTZ160

Certification GOST,CE, ISO

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Tower crane
1. CE approved, ISO and GOST certification
2. Complete safety devices
3. Good quality&competitive price

CANMAX Tower Crane

1. main technical parameters for CANMAX TC6010 tower crane:

Certificate		CE,ISO9001,Gost,
lifting moment		1250KN.m
Biggest lifting weight		10t
Biggest working range/lifting weight		60m/1.6t
Smallest working range		2.5m
Hoisting height	Fixed form	50m
	Attached form	161m
Hoisting system (planet differential type)	Hoisting speed/ Biggest lifting weight	Two falls		Four falls
		m /min	t	m /min	t
		3.14	5	1.57	10
		10.8	5	5.4	10
		33.9	5	16.95	10
		45.4	2.5	22.7	5
		68.1	2.5	34.05	5
slewing system	Slewing speed	0.6r/min
Trolley system	Trolley speed	0-69m/min
Jacking system	Rating jacking speed	0.6m/min
Lifting boom’s length/correspond balanced weight		60/15.7m/t
Crane total weight		53t
crane total power(not including the hoisting motor)		60kw
Mast section’s size (dimension)		1.7×1.7×3.0m
Section’s size of the lifting boom		1.356×1.00m
