Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Grader > 300hp Motor Grader
300hp Motor Grader
US$ 268,450 - 272,100
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
XCMG
Model Number:
GR300
Payment & Shipping
Payment Methods:
Port of Shipment:
any port of China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Brand Name
XCMG
Model Number
GR300
Specifications
1. comfortable cab with aircondition2. optional dozer, ripper.
3. competitive price and considerate service.
Basic specification | |
|---|---|
| Engine model | QSL9 |
| Rated power/speed | 224kW/2100rpm |
| Dimension(LxWxH) | 10500×3100×3550mm |
| Operating weight(Standard) | 26000kg |
Performance specification | |
| Travelling speed ,forward | 5,8,11,19,23,40 km/h |
| Travelling speed ,reverse | 5,11,23 km/h |
| Tractive force(f=0.75) | 140KN |
| Max. gradeability | 30% |
| Tire inflation pressure | 350 kPa |
| Working hydraulic pressure | 16 MPa |
| Transmission pressure | 1.3~1.8MPa |
Operating specification | |
| Max. steering angle of front wheels | ±50° |
| Max. lean angle of front wheels | ±17° |
| Max. oscillation angle of front axle | ±15° |
| Max. oscillation angle of balance box | 15 |
| Frame articulation angle | ±27° |
| Min. turning radius using articulation | 8.0m |
| Biade | |
| Maximum lift above ground | 450mm |
| Maximum depth of cutting | 500mm |
| Maximum blade position angle | 90° |
| Blade cutting angle | 28°—70° |
| Circle reversing rotation | 360° |
| Moldboard width X height | 4920×787mm |
| |
