Telescopic Handler 2.5t

Name: Telescopic Handler 2.5t
Brand: CANMAX
SKU: 141325156
Availability: InStock

US$ 30,000 - 40,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Shanghai, China

Brand Name:

CANMAX

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

main ports in China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shanghai, China

Brand Name CANMAX

Model Number 2.5T

Type Powered Pallet Truck

Power Souce Diesel Engine

Rated Loading Capacity 2.5T

Max. Lifting Height 6M

Min. Lifting Height 3M

Overall Dimensions 5560*2300*2565mm

Certification ISO

Specifications

As a specialist in this area, we can offer you the very best telescopic handlers at competitive prices.

Model	SZF25-4-L
Lifting capacity (max)	2500kg
Lift capacity at maximum reach	1000kg
Lifting height (max)	6000mm
Forward reach (max)	3260mm
Overall weight	7100kg
Transmission	Hydro-mechanical transmission
Drive type	Four wheel drive
Boom segments	2 segments
Size
Overall length	5560mm
Overall width	2300mm
Overall height	2565mm
Wheelbase	2200mm
Tread	1900mm
Ground clearance (min)	310mm
Performance
Steering modes	Rear wheel steering
Travel speed (max)	30km/h
Range of lateral displacement devices	left 100mm , right 100mm
Power
Engine	Cummins Turbo diesel 4BT3.9-C80
Rated power	80/60KW
Ful tank capacity	115(L)
Hydraulic tank capacity	102(L)
