Brand New 45T Container Reach Stacker
USD $385,000 - $386,000
/ Unit
1 Unit(Min.Order)
- 100 Unit / Units per Month
- Any Port of China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
Condition: | New | Place of Origin: | Shanghai, China | Brand Name: | CANMAX |
Model Number: | SRSC45C30 | Type: | Other | Power Souce: | Diesel Engine |
Rated Loading Capacity: | 45T | Max. Lifting Height: | 15100 mm | Overall Dimensions: | 11259*4188*4770mm |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1. Original VOLVO engine, 256kw/2100rpm2. Germany Kessler D102 with wet disc brakes
3. DANA CLARK Transmission
45T REACH STACKER SRSC45C30
Lifting capacity: | 45000 kg |
Max. Lifting height: | 15100 mm |
Boom angle: | 0-60° |
Min. ground clearance: | 400 mm |
Min. turning radius: | 8000 mm |
Tread (front wheel/rear wheel): | 3033/2750 mm |
Wheelbase: | 6000 mm |
Dimension (length×width×height): | 11259×4188×4770mm |
Dead weight: | 69 t |
Engine: | VOLVO TWD1340VE (Sweden)-6 cylinders 12 litres |
Power rating: 256 kW at 2100 rpm | |
Torque rating: 1770 Nm at 1260 rpm | |
Transmission: | DANA CLARK 15.5HR36000 4 gears fwd/ 4 rev |
Fully automatic transmission | |
Drive axle: | Kessler D102 with wet disc brakes |
