Home > Manufacturing & Processing Machinery > Crane > Other Cranes > 55ton Rough-terrain Crane RT550

55ton Rough-terrain Crane RT550

Name: 55ton Rough-terrain Crane RT550
Brand: ZOOMLION
SKU: 141324794
Availability: InStock

55ton Rough-terrain Crane RT550 thumbnail-1

US$ 290,000 - 300,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Max. Lifting Load:

55T

Max. Lifting Height:

1967KN.M

Contact Supplier Request Quote Chat Now

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port of China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Max. Lifting Load 55T

Max. Lifting Height 1967KN.M

Place of Origin Hunan, China

Brand Name ZOOMLION

Model Number RT550

Specifications

1.Powerful Cummins engine QSB6.7, 160KW/2500RPM
2.Full version operation Cab
3.Kessler axle
4.TUV certificate
5.4 by 4 drive

The machine adpot four wheel drive and four wheel steering, so the machine have three kind moving control, two wheel steering, four wheel steering and crabbing.

Short wheelbase design make the machine very convinient in narrow space, minimum turning diameter.

Item	No.	Specification	Unit	Value
Working performance specification	1	Max. rated total lifting capacity ×working radius	kg.m	55000×3.0
	2	Max. load moment of basic boom	kN.m	1967
	3	Max. load moment with max. main boom length	kN.m	1126
	4	Max. lifting height of main boom	m	34.8
	5	Max. lifting height of fly jib	m	52.4
Dimension specification	6	Overall dimensions(L×W×H)	mm	13100×3300×3750
	7	Outrigger spa(portrait×transy)	mm	6900×6900
	8	Main boom length	mm	10800~34000
	9	Fly jib length	mm	10000~17000
	10	Main boom angle°	°	-3~78
	11	Swing range		360°continuing
Working speed	12	Max. speed of single rope on main winch m/min	m/min	150
	13	Extend time of Boom	s	100
	14	Retraction time of Boom	s	80
	15	Rising time of boom	s	56
	16	Laydown time of boom	s	63
	17	Slewing speed	r/min	0~2.5
Hydraulic system	18	Rated working pressure	MPa	27
	19	Rated working flux	L/min	400
	20	Volume of Hydraulic oil tank	L	700
Mass specification	21	Deadweight of crane in traveling condition	kg	39200
	22	Front axle load	kg	20440
	23	Rear axle load	kg	18760
Traveling specification	24	Max. traveling speed (Advance/back)	km/h	39/15
	25	Wheelbase	mm	3950
	26	Wheel track(Front/Rear)	mm	2605
	27	Max. grade ability	%	110
