Home > Manufacturing & Processing Machinery > Crane > Other Cranes > 50ton ZOOMLION Crawler Crane

50ton ZOOMLION Crawler Crane

Name: 50ton ZOOMLION Crawler Crane
Brand: ZOOMLION
SKU: 141324796
Availability: InStock

50ton ZOOMLION Crawler Crane thumbnail-1

US$ 147,000 - 153,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Max. Lifting Load:

55T

Max. Lifting Height:

58M

Contact Supplier Request Quote Chat Now

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port of China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Max. Lifting Load 55T

Max. Lifting Height 58M

Place of Origin Hunan, China

Brand Name ZOOMLION

Model Number QUY50

Specifications

1.Weichai engine WP6G190E26 140kW
2.Three winches(Main winch, Auxiliary winch and trolley winch)
3.Automatic dismentle

1. The control system applied to this type of crane is an electronic management system, which adopts CAN bus technology, has intelligent fault diagnosis function and is equipped with intelligent color display.
2. The pendant plate made of high-strength plate, which has taken the place of traditional wire rope, has the advantages of excellent rigidity, light weight, great load-bearing capacity and low wind drag etc.
3. The crane is equipped with a self-assembly/dismantling system. No auxiliary crane is required for loading, unloading, assembly and dismantling.
4. The actuating time of brakes and the opening time of valves fitted in winch mechanisms can be adjusted freely to optimum matching state. The applied advanced PLC controller can make every speed parameter be adjusted within specified range in accordance with the user’s habit, which embodies the ergonomic design of our crane.
5. The slewing mechanism has controllable free swing function which can reduce the impacts on the crane and ensure that superstructure starts/stops slewing more stably. The external slewing ring and slewing reducer with great load-bearing capacity and high precision can ensure stable and precise slewing motion.
6. The traveling mechanism can make the crane have high maneuverability and perform such motions as traveling in straight line, one-side crawler steering, differential steering and turning on the spot as well as traveling with load.
7. The crane has free-fall function.
8. The main pump control system, which has the functions of advanced load feedback and electrically-controlled power adjustment, makes the crane have good jogging performance so as to satisfy the demands in different working conditions required by customers.

Item		Value	Remarks
Max. lifting capacity × Radiust ×m		55×3.7
Deadweight with basic boom t		48
Main boom length m		13~52
Fixed jib length m		6~15
Max. lifting capacity of fixed jibt		5
Offset angle of fixed jib°		10,30
Max. length of main boom with fixed jibm		43+15
Max. speed of single rope on drum	Main winchm/min	120	The 4^th rope layer
	Auxiliary winchm/min	120	The 4^th rope layer
	Derricking winchm/min	60	The 4^th rope layer
Slewing speedrpm		0~3.0
Traveling speedkm/h		0~1.6
Gradeability%		40
Ground pressureMPa		0.066
Overall dimensions (L×W×H)mm		6800×3300×3020
Engine	Rated power/ rotational speedkW/rpm	132/2200
	Max. output torque/ rotational speedNm/rpm	750/1300
	Emission standard	EU Stage 3
Crawler gauge × ground contact length × track shoe widthmm		2540×4700×760	Crawler carrier retracted
Crawler gauge × ground contact length × track shoe widthmm		3540×4700×760	Crawler carrier extended
