0.38m3 Skid Steer Loader

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.
0.38m3 Skid Steer Loader thumbnail-1
0.38m3 Skid Steer Loader photo-1
US$ 18,000 - 23,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
CANMAX
Model Number:
FW750
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
any port in China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name CANMAX
Model Number FW750
Place of Origin Zhejiang, China
Type Skid Steer Loader
Moving Type Wheel Loader
Rated Load 800kg

Specifications

1.Good quality,low price.
2.Imported hydraulic parts,professional service.
3.Operating capacity:800kg

 Skid steer loader FW750





Engine:



Perkins

804D-33

Rated power(KW/rpm)

47/2500

Max Tloquemoment(N.M/rpm)

200/1600

Number of Cylider

4

Displacement(L)

3.3





Transmission Agent



Running speed(double speed)km/h

0-12

Tyre

10.0-16.5 10PR





Performance:



Operating Capacity(kg)

800



Tipping load(kg)

1600

Lifting Mechanism

Radial Lift

max prying force(N)

22000





Hydraulic System



Saft Pressure(bar)

210

Rated Flow(L/min)

65

Exclusive Robotistic Rated Folw(L/min)



Servo Hydraulic System Rated Flow(L/min)



High flow optional(L/min)







DIMENSIONS



Height to cab top(mm)

2092

Length with bucket(mm)

3415

Length without bucket(mm)

2600

Overall width(mm)

1740

Bucket width(mm)

1730

Tread(mm)

997





Operating Extent



Max. dump height(mm)

2300

Dump distance(mm)

670

Height to bucket hinge pin(mm)

3065

Angle of departure

23

Ground clearance(mm)

190





General Information



Operating weight(kg)

2800

Feul tank capacity(L)

75

Bucket capacity(m3)

0.38



0.38m3 Skid steer loader0.38m3 Skid steer loader
