construction passenger hoist
- Tianjing
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Beijing, China | Brand Name | JCC | |
| Model Number | SC120 | Rated Loading Capacity(kg) | 1.2t | |
| Hoisting Speed | 33m/min | Max Lifting Height | 250m |
Product Description
Specifications
SC120KGS CONSTRUCTION HOISTCAPACITY: 1200KGS
SPEED: 33 M/MIN
CABIN: 3.0 *1.3*2.5
Packaging & Delivery
Packaging: | nude |
Delivery: | 10 days |
Main technical data | Unit | Value |
Rated load | kg | 1200 |
Rated erection load | kg | 1000 |
Jib attachment rated load | kg | 300 |
Cage size | m | 3.0×1.3×2.5 |
Maximum lifting height | m | 250 |
Lifting speed | m/min | 33 |
Rated output | kW | 2×11 |
Voltage rating | V | 380/440 |
Rated frequency | Hz | 50/60 |
Rated current | A | 2×23.5 |
Power supply fuses | A | 63 |
Protective class | / | IP55 |
Load duration factor | / | FC-25% |
Safety device | m/s | 1.2 |
Enclosure weight | kg | 980 |
Cage weight | kg | 1750 |
Mast section weight | kg | 125/145 |
Mast section length | mm | 1508 |
