Construction Hoist/Lifter/Elevator SC200/200
As leading supplier for consturction holist with 20 years development, we-CANMAX-offer high quality elevators with different capacity which ranges from 1000kg,1200kg, 2000kg. The normal low speed is at 33 m/min, while middle speed is at 0-45m/min and high speed 0-63m/min. And also provide the different dimension of cage to satisfy the special demand from the customers.
1. detailed information of construction hist
| Item | SC200/200 |
| Pay-load capacity(per cage)(kg) | 2x2000 |
| Lifting speed(m/min) | 0-33; 0-45; 0-63 m/min |
| Max lifting height(m) | 150m |
| Power supply voltage/frequency | 380-415V/50HZ;440-460V/60HZ or according to local |
| Cage inner dimension(l*w*h) | 3 X 1.3 X 2.5m |
| Mast section(l*w*h)(m) | 0.65 X 0.65 X 1.508 m |
Standard Section Height(m) |
1.508 m |
| Number of motors/cage | 3 |
| Rated motor power(KW) | 18.5*3 |
| Weight of mast section(KG) | 195 |
| Transducer power (KW) | 75 |
| Brand | canmax |
2 . Features of SC200/200 construction hoist
1. It is equipped with fully safety devices to guarantee the safe working,
2. Stable running and comfortable adaptability.
3. The transmission system adopted three drive motors and three sets of reduction gears
4. It has simple electrical control system, convenient to be maintained and low failure rate
3. structure picture
