90 Hp Wheel Tractor

90 Hp Wheel Tractor thumbnail-1
90 Hp Wheel Tractor photo-1
US$ 18,000 - 26,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port of china
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Certificate CE
Brand Name LOVOL
Model Number TD904
Place of Origin Shandong, China

Specifications

90 Hp wheel tractor
1. Excellent quality,competitive price.
2. Drive type:4*4.
3.World famous brand, professional service

LOVOL TD904 Wheel Tractor



1. The U.S. DANA front driving axle is optional;
2. Germany Luk clutch and STABILUS hood gas spring have a high reliability;
3. The use of flat floors, hanging pedals, side manipulation, 16+8 shuttle shift transmission, various gear selections and optional 8+8, 8+4 and 16+8 crawling gears, and 16+16 synchronized shuttle shift model, can provide a reasonable velocity distribution, and a good operating adaptability;
4. The 145-liter lower large fuel tank has a long operation time;
5. The U.S. ACTUANT combination instruments are optional;
6. EC, EPA and GOST certification models are available;
7. The optional models with stepless and adjustable tread have a good operating adaptability;
8. The optional widened tread with a high ground clearance can achieve intertillage, spraying, laminating and other field operations.



Drive type 4*4
Overall dimension(L * W * H) 4530*2050*2810
Wheelbase (mm) 2195
Track(front/rear) 1610~1950/1608~1996
Track(front/rear) regulating method Step/stepless
Min.Ground clearance(mm) 405
Min.operating weight (without cab)(kg) 4155
Min.operating weight (without cab)(kg) 3855
Counterweight (max) (front/rear) 440/480
Gears(forward/reverse/creeper) 8+4/16+8 shuttle type /16+8 creeping/16+16
Theoretical speed of each gear(forward/reverse) 0.4-33.3/0.6-10.3;1.5-32.2/2.3-32.2;2.2-33.3/3.0-10.3;2.5-39.31/2.62-41.31
