45 hp Wheel Tractor

45 hp Wheel Tractor thumbnail-1
45 hp Wheel Tractor photo-1
US$ 6,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
2WD
Contact Supplier Request Quote Chat Now
Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port of china
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 2WD
Usage Farm Tractor
Drive Type Other
Power(W) 36.8kw
Certificate CE
Brand Name LOVOL
Model Number TB450E
Place of Origin Shandong, China

LOVOL TB450E Wheel Tractor





1. The fan and heater cab are optional;
2. 955mm narrow tread model can better meet the operational requirements;
3. U.S. ACTUANT combination instruments are optional;
4. The transmission with gear combinations of 8+8, 16+8, and 12+12 has a variety of gear selections, and a reasonable velocity distribution;
5. Chassis uses the four-planetary gear differential, and the power is upgraded to 60 hp;
6. EC, EPA and GOST certification models are available.



Drive type 4*2
Overall dimension(L * W * H) 3980*1650*(2130/2520)
Wheelbase (mm) 1966
Track(front/rear) 1150-1450/1200-1500
Track(front/rear) regulating method Step/stepless
Min.Ground clearance(mm) 400
Min.operating weight (with cab)(kg) 2210
Min.operating weight (without cab)(kg) 2030
Counterweight (max)(front/rear) 144/360
Gears(forward/reverse/creeper) 8+4/8+8/16+8
Theoretical speed of each gear(forward/reverse) 2.65-37.78/2.33-30.49;2.46-32.73/2.15-28.69;0.43-5.7/0.65-1.97;2.24-29.91/1.97-26.22
Engine
Brand Lijia, Xinchai, Quanchai
Engine type 4-cylinder
Intake mode Natural intake
Number of cylinders 4
Bore 95
Stroke 105
Displacement(L) 2.977
Engine rated power kW@rpm 33.1
Rated speed 2400
Type of air cleaner Dry or wet type
Type of cooling system Forced water-cooled
Max. Torque@ revolving speed (rpm) 170@1600~1800
Specific fuel consumption rate at rated conditions (g/kW.h) ≤248
Fuel tank capacity (L) 38
Steering brake system
Type of steering system Hydraulic/mechanical
Type of steering gear Cycloid orbitrol steering gear
Type of braking system Disc type
Transmission system
Clutch type Single-action/double action
Gearbox type Two-axis mechanical gearbox
Gearbox shift mode Shift sleeve
Type of central transmission Spiral bevel gear type
Final transmission mode (front/rear) Planetary gear type
Walking system
Frame type Frameless
Tire Model (front/rear) 6.0-16/12.4-28
Working device
Type of hydraulic suspension system Open-center, semi-separated type
Type of linkage Three point rear linkage
Linkage classes Class II
Lift capacity(610mm point))kN 8.3
Regulating mode Force or position independent control
Type of PTO shaft Rear semi-detached type
The number of PTO shaft splines 6 splines/8splines
Outer diameter of PTO shaft spline φ35/φ38
PTO shaft speed 540/760 or 540/1000 or 760/1000
Hydraulic system
Hydraulic output flow (L/min) 23
