105-125 Hp Wheel Tractor

105-125 Hp Wheel Tractor thumbnail-1
105-125 Hp Wheel Tractor photo-1
US$ 13,000 - 16,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port of china
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Brand Name LOVOL
Model Number TF1254
Place of Origin Shandong, China

Specifications

105-125 Hp wheel tractor
1. Excellent quality,competitive price.
2. Drive type:4*4. World famous brand, professional servic

LOVOL  TF1254 Wheel Tractor



1. The use of flat floors, hanging pedals, side manipulation, 16+8 shuttle shift transmission, and various gear selections can provide a reasonable velocity distribution. Optional 16+16 synchronizer shuttle shift models make the manipulation more convenient;
2. The imported German LUK clutch has a reliable performance, a large torque reserve coefficient and a high transmissiton ability;
3. 240-liter lower large fuel tank, a long operation time;
4. The optional U.S. ACTUANT combination instruments can achieve a stable work and a high reliability;
5. GOST certification model is available.



Drive type 4*4
Wheelbase (mm) 2582/2657(Front Drive Axle of Midengine Steering Fuel Cylinder)
Track(front/rear)regulating method 1784~2202/1620~2420
Min.operating weight(kg) 5545
Gears(forward/reverse/creeper) 16+8
Brand Lovol Power
Intake mode Supercharged
Bore 100
Displacement(L) 6
Rated speed 2200
Type of cooling system Forced water-cooled
Specific fuel consumption at rated conditions (g/kW.h) ≤248
Type of steering system Hydraulic steering
Type of braking system Wet type, disc type, static hydraulic control
Gearbox type Two-axis mechanical gearbox
Type of central transmission Spiral bevel gear type
Frame type Frameless
Type of hydraulic suspension system Open-center, separated type
Linkage classes Class II
Regulating mode Depth control, floating control
The number of PTO shaft splines 6 /8/21 splines
PTO shaft speed 540/1 000 or 760/1 000
Overall dimension(L * W * H) 5060*2345*2995
Track(front/rear) 1784~2202/1620~2420
Minimum ground clearance 395
Counterweight (max) (front/rear) 440/516
Theoretical speed of each gear(forward/reverse) 1.25-29.71/2.0-27
Engine type In-line, four-stroke
Cylinder number 6
Stroke 127
Engine rated power kW@rpm 92
Air cleaner type Dry type
Max. Torque@ revolving speed (rpm) 421/1500~1700
Fuel tank capacity (L) 240
Type of steering gear Cycloid orbitrol steering gear
Clutch type Dry type, double-action clutch
Gearbox shift mode Shift sleeve
Final transmission mode(front/rear) Single-stage spur gear
Tire Model (front/rear) 14.9-26/18.4-38
Type of linkage Three point rear linkage
Elevating force(610mm)kN ≥25
Type of PTO shaft Rear separated type
Outer diameter of PTO shaft spline φ35/φ38/φ35
Hydraulic output flow (L/min) 70
