High Quality TELESCOPIC BOOM LIFTS

Name: High Quality TELESCOPIC BOOM LIFTS
Brand: CANMAX
SKU: 141323824
Availability: InStock

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Max. Lifting Load:

340-480kg

Max. Lifting Height:

38.5m

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Max. Lifting Load 340-480kg

Max. Lifting Height 38.5m

Place of Origin Hunan, China

Brand Name CANMAX

Model Number GTBZ28

Certification CE

Warranty 1 YEAR

After-sales Service Provided Engineers available to service machinery overseas

Item	Measurement	Item	Measurement
Dimensions		Productivity
Overall length(stowed)	12.5M (41ft)	Platform height max.	36.5M (120ft)
Overall width(stowed)	2.49M (8ft)	Working height max.	38.5M (126ft)
Overall height(stowed)	3.08M (10ft)	Horizontal reach max.	22M (72ft)
Ground clearance	0.43M (1.4ft)	Turntable rotation	360°continuous
Wheelbase	3.66M (12ft)	Platform rotation	160°
Overall weight	20100kg (4WD)	Platform Load capacity	340kg (non-restricted)
Overall weight	20100kg (4WD)	Platform Load capacity	480kg (restricted)
Platform Size (LWH)	2.440.911.1M (8ft3ft3.6ft)	Grade ability	40% (4wd)
Platform levelling	Automatic	Turning radius(outside)	5.57M (18ft)
Tire specification	12.00-20	Turning radius(inside)	2.56M (8ft)
Tire type	Solid	Turntable tailswing	1.82M (6ft)
Power		Max. Driving Speed	4.4KM/H
Hydraulic tank vol.	200L	Driving Speed (stowed)	0~4.4km/h
Hydraulic system vol. (inc. the tank)	300L	Driving Speed (extended)	0~1.1km/h
Fuel tank vol.	150L	Max allowable wind force	12.5m/s
Control voltage	24V	Max allowable slope	3°
Engine	Original Cummins B3.3 80hp	Max noise on normal use	82dB(A)
Drive & steer model	4WD*4WS	Max allowable side force	400N
