4 ton Truck Crane
4ton cheap truck crane
mini crane
4T 20M
Low Price Low Freight
1 set truck crane can packed in 1 container
4ton cheap truck crane
spare parts for one year free
1set truck crane can packed in 1container
Model Number |
QG-4T |
Rated loading capacity |
4T |
Rated lifting moment |
100,000NM |
Max. lifting load |
4T |
Max. lifting height |
20m |
diesel engine type |
ZD30 |
power |
22kw |
Chassis type |
ST4 |
Chassis Brand |
WRBM |
Lifting speed |
24.6m/min |
Steering speed |
0-2rpm |
Drving speed |
45km/h |
Span |
2.7x3.4m |
Overall dimensions(L×W×H) |
6.9×2×2.6m |
weight |
4000 kg |
4T mini truck crane Performance Table
Boom length (m) |
5m |
9.8m |
15m |
|||
Performance |
Lifting capacity (kg) |
Height (m) |
Lifting capacity (kg) |
Height (m) |
Lifting capacity (kg) |
Height (m) |
Working radius (m) |
|
|
|
|
|
|
2.5 |
4000 |
6.6 |
|
|
|
|
3 |
3000 |
6.0 |
1450 |
11.5 |
|
|
3.5 |
2200 |
5.5 |
1200 |
11.3 |
750 |
16.70 |
4 |
1850 |
5.0 |
1100 |
11.15 |
700 |
16.60 |
4.5 |
1700 |
4.5 |
950 |
11.00 |
600 |
16.45 |
5 |
|
|
850 |
10.70 |
550 |
16.30 |
6 |
|
|
800 |
10.40 |
450 |
16.14 |
7 |
|
|
700 |
9.75 |
400 |
15.75 |
8 |
|
|
|
|
380 |
15.27 |
9 |
|
|
|
|
350 |
14.70 |
10 |
|
|
|
|
300 |
14.00 |
11 |
|
|
|
|
250 |
13.20 |
12 |
|
|
|
|
200 |
12.20 |
13 |
|
|
|
|
150 |
11.00 |
1. Working radius in Table 2 is the actual radius after hoists, which means the distance from hoist center to rotary center of revolving stage.
2. Lifting capacity and height are calculated according to boom, revolving stage, and outrigger strength and crane stability. Overload operation is prohibited in order to prevent accidents as crane rollover or break event due to mechanical deformation.
3. Lifting capacity is the maximum weight when operates from the crane rear. It should be reduced by 30% when operates from crane side.
And all mini truck crane can be packed in one 40`H container
