Specifications
River sand pumping boat1.Dredging depth:>25m
2.Working capacity:100-400m3/h
3.Usage:loose sand layer
4.ISO9001
Best Capacity River Sand Pumping Boat For Sale
Feature
1. Economic and high sand dredging efficiency
2.Portable to move
3.Easy to operate with reliable quality
4.Standard world-wide available gearboxes and hydraulic components
5.Operation by one man from spacious and low noise operating cabin
6.Controls and instruments mounted in ergonomic dash board
Parameter
| Model | KDSX200-10 | KDQSB200-5 |
| Dredger Body | ||
| Dimention (m) L*W*H | 14*4.2*1.4m | 12*4.7*1.2 |
| Float | ||
| Pontoon | ||
| Side pontoons 2sets | 11.5*1.0*1.4m | 11*1.25*1.2 |
| Main pontoon 1set | 8.5*2.25*1.4m | 8*2.25*1.2 |
| Material | CCSA | CCSA |
| Total weight T | 30 | 20T |
| Pump model | 6/4”D-G | ZJQ300-20-37 |
| Rotation speed(r/m) | 1150 | 980 |
| Dredging data | ||
| Standard dredging depth | 8-10m | 5M |
| Standard discharge distance | 500m | 50M |
| Max.dredging depth(m) (optional) | 10m | 8M |
| Max.discharge distance (m) ( medium and fine sand<0.235mm when min.flows) | 600m | 70M |
| Max.standard dredging capacity m3/h | 50m3/h | 50-70m3/h |
| Min.clean water flows(standard dredging depth and Max.discharge distance) | 250m3/h | 300m3/h |
| Suction pipe diameter(mm) | 200 | |
| Discharge pipe diameter(mm/inch) | 200 | 200mm |
Submersible Sand Pump Boat in the workshop
Pump
Submersible Sand Pump Boat Working sketch
Submersible Sand Pump Boat Work site
1.Qingzhou Keda Mining Machine Co., Ltd.
2.The main products are:
2)Dredger
We attach the development of scientific research, and form strategic partnership with the major research institutions. And we had established good cooperation with Import and export trading company, established Shandong magnetic equipment Research Instituting. We have CAD Aided Design R & D center and physical mineral processing laboratory,can work out reasonable and practical solution according to customer's technical requirements and work site,also had established and improve the equipment file and service system, concentrating on customer feedback to make the products constantly improved to meet the customers' different needs.
3.Certificate
4.The Clients visit our company
Our engineers will personally to the customer's work site installation and debugging.
1.KD Company signs a long-time after-sale service agreement with customers.
2.We provide rational and practical design according to customers' request.
3.We send engineers to assemble and test the machine within the time in the contract.
4.Within warranty period,we provide free repair if quality problems emerge.
5.We provide free training of operation and maintainance for customers.
6.We supply high quality accessories in low price.
7.We make an excellent filing of customers for long-term following-up service.
