Specifications
China Supplier Submersible Pump Dredging Equipment For Sale1.ISO 9001
2.With patent
3.Good aftersale service
4.Low fuel
China Supplier Submersible Pump Dredging Equipment For Sale
1. Submersible Pump Dredge Ship Specification is as follows:
1. Economic and high sand dredging efficiency
2.Portable to move
3.Easy to operate with reliable quality
4.Operation by one man from spacious and low noise operating cabin
5.We are original factory,without middle link,the high quality and reasonable price will be guaranteed.
2. Submersible Pump Dredge Ship Parameter:
| Model | KDSX200-10 | KDQSB200-5 |
| Dredger Body | ||
| Dimention (m) L*W*H | 14*4.2*1.4m | 12*4.7*1.2 |
| Float | ||
| Pontoon | ||
| Side pontoons 2sets | 11.5*1.0*1.4m | 11*1.25*1.2 |
| Main pontoon 1set | 8.5*2.25*1.4m | 8*2.25*1.2 |
| Material | CCSA | CCSA |
| Total weight T | 30 | 20 |
| Pump model | 6/4”D-G | ZJQ300-20-37 |
| Rotation speed(r/m) | 1150 | 980 |
| Dredging data | ||
| Standard dredging depth | 8-10m | 5m |
| Standard discharge distance | 500m | 50m |
| Max.dredging depth(m) (optional) | 10m | 8m |
| Max.discharge distance (m) ( medium and fine sand<0.235mm when min.flows) | 600m | 70m |
| Max.standard dredging capacity m3/h | 50m3/h | 50-70m3/h |
| Min.clean water flows(standard dredging depth and Max.discharge distance) | 250m3/h | 300m3/h |
| Suction pipe diameter(mm) | 200 | |
| Discharge pipe diameter(mm/inch) | 200 | 200mm |
.
3. Submersible Pump Dredge Ship show
River Submersible Pump Dredge Ship Without Cutter Head
Submersible Pump Dredge Ship Pump
Submersible Pump Dredge Ship With Cutter Head
Submersible Pump Dredge Ship With Cutter Head Pump--Used for soild soil and sand
4.About our company
1)We are one professional manufacturer and exporter of hydraulic cutter suction dredger and some related products.
2)we had established good cooperation with Import and export trading company, established Shandong magnetic equipment Research Instituting.
3)The dredger has passed ISO quality system certification and Chinese Classification Management System Certification with good quality and low price.
4)We have CAD Aided Design R & D center and physical mineral processing laboratory,can work out reasonable and practical solution according to customer's technical requirements and work site,
5.Contact Person:
Send Inquiry to This Supplier
