Hot Sale Small Submersible Pump Dredger
US$ 15,000 - 44,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Submersible Pump Sand Dredger
Power Type:
Electric
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Submersible Pump Sand Dredger For SaleUS$ 15,000 - 44,000MOQ: 1 Unit -
2015 Hot Small River Sand Suction DredgerUS$ 60,000 - 500,000MOQ: 1 Set
-
Best Quality Submersible Pump Mining Ship For SaleUS$ 15,000 - 44,000MOQ: 1 Unit
-
Best Quality Submersible Pump Mining Vessel For SaleUS$ 15,000 - 44,000MOQ: 1 Unit
-
Best Quality Submersible Pump Mining Boat For SaleUS$ 15,000 - 44,000MOQ: 1 Unit
Condition
New
Type
Other, Submersible Pump Sand Dredger
Power Type
Electric
Dredging Depth
30 m
Draught
80 cm
Place of Origin
Shandong, China
Brand Name
KD
Model Number
KEDA
Weight
15T
Certification
ISO9001
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Submersible Pump Dredger1.Dredging depth:>25m
2.Working capacity:100-400m3/h
3.Usage:loose sand layer
4.ISO9001
Hot Sale Small Submersible Pump Dredger
1.Feature:
1. Economic and high sand dredging efficiency
2.Portable to move
3.Easy to operate with reliable quality
4.Standard world-wide available gearboxes and hydraulic components
5.Operation by one man from spacious and low noise operating cabin
6.Controls and instruments mounted in ergonomic dash board
2.Parameter
| Model | KDSX200-10 | KDQSB200-5 |
| Dredger Body | ||
| Dimention (m) L*W*H | 14*4.2*1.4m | 12*4.7*1.2 |
| Float | ||
| Pontoon | ||
| Side pontoons 2sets | 11.5*1.0*1.4m | 11*1.25*1.2 |
| Main pontoon 1set | 8.5*2.25*1.4m | 8*2.25*1.2 |
| Material | CCSA | CCSA |
| Total weight T | 30 | 20T |
| Pump model | 6/4”D-G | ZJQ300-20-37 |
| Rotation speed(r/m) | 1150 | 980 |
| Dredging data | ||
| Standard dredging depth | 8-10m | 5M |
| Standard discharge distance | 500m | 50M |
| Max.dredging depth(m) (optional) | 10m | 8M |
| Max.discharge distance (m) ( medium and fine sand<0.235mm when min.flows) | 600m | 70M |
| Max.standard dredging capacity m3/h | 50m3/h | 50-70m3/h |
| Min.clean water flows(standard dredging depth and Max.discharge distance) | 250m3/h | 300m3/h |
| Suction pipe diameter(mm) | 200 | |
| Discharge pipe diameter(mm/inch) | 200 | 200mm |
3.Production
