Specifications
Gold Dredging Machine1.ISO9001:2008, SGS
2.High cost performance
3.Portable, easy operation
4.Small scale gold panning
CN Top Seller Small Size Gold Dredging Machine
1.Features
1).ISO9001:2008, SGS, used for small scale gold panning
2).High processing capacity: up to 17m³/h
3).Reliable performance, safe, high efficiency
4).High cost performance, good after sales service
2.Parameter
Mini Gold Dredger | |||
Model | QFT3-2 | QFT3 | QFT4 |
Dimension | 2300*1500*1000mm | 3200*2500*1200mm | 3200*1500*1000mm |
Diesel |
|
|
|
Model | WH—15S | Honda GX270 | Honda GX390 |
Power | 5hp | 11hp | 13hp |
Pump | 1set | 1set | 1set |
Dimension(L*W*H) | 550*450*450mm | 550*470*450mm | 550*500*480mm |
Pump Diameter | 50mm(2inch) | 80mm(3inch) | 100mm(4inch) |
Water Flow | 33m³/h | 60m³/h | 80m³/h |
Dredging depth | 0.5-1.2m | 0.5-3m | 0.5-3m |
Work Capacity | 1-7m³/h | 5-12m³/h | 8-17m³/h |
Gold Chute |
|
|
|
Dimension(L*W) | 400*1500mm | 500*1700mm | 500*1700mm |
Float |
|
|
|
Dimension(L*W*H) | 1600*395*370mm | 1600*395*370mm | 1600*395*370mm |
Suction Pipe | 3inch | 3inch | 4inch |
3.Product Display
1.We are a modern large-scale machinery manufacturer devoting ourselves to the fields of desiting, sand pumping and gold mining with engineering design, producing, installation, commissioning and high quality after sales service.
2.All our products have been certified by ISO9001 and many of them have been exported to more than fifteen countries, such as Cote d'Ivoire, Colombia, Fiji, Ghana, Bangladesh, Sultan, Korea, USA, Russia, India and so on.
Certification
Clients Visiting Workshop
Recent Success Cases
1.Mining project consulting will be provided by our experienced engineers.
2.Testing sample in laboratory will be available all the time.
3.Providing whole production line equipments and spare parts.
4.Dispatching engineer overseas guidance for equipment installation.
5.Train clients' local first batch workers and make them operate expertly.
6.Help solve the problems on the equipment operation.
1. Is our company a direct or indirect producer?— Our company is a direct producer.
2. What's the main product of our company? — Our main product is gold extracting equipment.
3. Are our products certified or patented? — Yes, we only provide certified products.
4. Can we offer good after sale service? — Yes, the warranty of all our products is one year and all spare parts will be provided fast and cheap forever.
You are invited to create a bright future with us. Please contact!
Contact: Chance Ji
Tel/Fax: 0086-0536-3811221
Skype: kedamachinery07
E-mail: sales07 @miningmachine.net
