good quality best trailing suction hopper dredger for sale with SGS
- 30 Set / Sets per Month
- Qingdao
- Credit Card PayPal
- bucket wheel excavator 2000m3/h-7000m3/h
- bucket wheel excavator 500m3/h-7000m3/h
- bucket wheel excavator 500tph-2500tph
- 2021 Hot newest small 350 1000m3 Cutter Suction Dredger
- Hot Newest Sand Suction Dredging Boat Dredger for Sale Engineers Available to Service Machinery Overseas Customized Provided MAP
- Sand Dredging Machine 2021 Hot Newest Small 12 Inch Cutter Suction Dredger Engineers Available to Service Machinery Overseas MAP
Product Details
Condition: | New | Type: | Cutter Suction Dredger | Power Type: | Diesel |
Dredging Depth: | 15 m | Draught: | 1500 cm | Place of Origin: | Shandong, China |
Brand Name: | KD | Model Number: | KDCSD | Dimension(L*W*H): | 12.5*4.6*1.3m |
Weight: | 60t | Certification: | ISO9001 | Warranty: | 1 year warranty |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
trailing suction hopper dredger for saleing capacity 100-1000m3/h
2.dredging depth 5-18m
3.discharge distance 1500m
Trailing suction hopper dredger for sale
1.Features
a.Design according to customer's requriments.
b.It is highly efficient with low cost, a best underwater dredging machine.
c.Simple,rapid assembly and dismantling.
The dredger is equipped with a rapid connection-disconnection system for the pontoons, achieved using bolts at deck level, and hooks at the bottom.
Further salient features of the vessel are the compact dredge pump drive incorporating a reduction gear with integrated pump bearing and a fresh water engine cooling system, based on the well cooling principle.
2.Basic parameter of trailing suction hopper dredger for sale
Basic CSD Parameter | |||||||
Model | KDCSD200 | KDCSD260 | KDCSD300 | KDCSD350 | KDCSD400 | KDCSD450 | KDCSD500 |
trailing suction hopper dredger for sale Body | |||||||
Dimensions(L*W*H)m | 12.5*4.6*1.4 | 12.5*5.8*1.6 | 14.5*5.8*1.8 | 14.5*5.8*1.8 | 22*6.4*2 | 26*7*2 | 26*7.1*2.2 |
Engine room(m) | 7.5*2.25*1.4 | 8*2.8*1.6 | 9*3.2*1.8 | 9.5*3.2*1.8 | 12*3.4*2 | 14*3.4*2 | 14*3.5*2.2 |
Dredging data | |||||||
Standard dredging depth | 6-7m | 6-8m | 8-10m | 10-12m | 12-14m | 12-14m | 12-14m |
Pump model | 8/6” | 10/8” | 12/10” | 12/10” | 14/12” | 14/12” | 450WN |
Water flow | 450m3/h | 800m3/h | 1100m3/h | 1500m3/h | 1900m3/h | 2500m3/h | 3200m3/h |
Suction pipeline diameter(mm/inch) | 260 | 300 | 350 | 350 | 400 | 450 | 500 |
Discharge pipeline diameter(mm/inch) | 200 | 260 | 300 | 350 | 400 | 450 | 500 |
Devices | |||||||
Total power KW | 176kw | 258kw | 353kw | 480kw | 640kw | 930kw | 1200kw |
Generator set(kw) | 24 | 24 | 24 | 24 | 24 | 36 | 36 |
Cutter head | |||||||
Diameter (mm) | 850-30 | 950-40 | 1100-50 | 1200-80 | 1300-110 | 1500-120 | 1700-140 |
Winch(hydraulic) | |||||||
Ladder winches | JC-3000 | JC-4000 | JC-4000 | JC-6000 | JC-6000 | JC-10000 | JC-12000 |
Swing winch | JC-3000 | JC-4000 | JC-4000 | JC-6000 | JC-6000 | JC-8000 | JC-10000 |
Spuds | |||||||
Quantity | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
Spuds length*diameter(mm) | 8600*273 | 11000*300 | 13000*350 | 15000*377 | 17000*450 | 17000*550 | 17000*600 |
Spuds weight/pic | 900kg | 1500kg | 2000kg | 2500kg | 3900kg | 4500kg | 5000kg |
Cummins Engine:which is global warranty,spare parts can be available in short time! Hydraulic values:Germany Rexroth series,famouse brand to make sure the dredger can be with reliable hydraulic system.
3. Equipment Component Show
Cutter head
Engine and Pump
4.Company Introduction
KEDA Mining Machine Co.,Ltd.
1). We are professional cutter suction dredger manufacturer with patent in china.
2).All products have been certified by ISO9001-2008. and have been exported to Ghana, Bangladesh, Sultan, Korea and so on.
Certificate files
5.Contact Us
Welcome to visit our factory and please feel free to contact me.
Peter Pan
Skype:kedamachinery03
E-mail:sales03(@)
