SGS certificated hydraulic dredger vessel sand mining dredger
- 15 Set / Sets per Month
- Qingdao
- Credit Card PayPal
- bucket wheel excavator 2000m3/h-7000m3/h
- bucket wheel excavator 500m3/h-7000m3/h
- bucket wheel excavator 500tph-2500tph
- 2021 Hot newest small 350 1000m3 Cutter Suction Dredger
- Hot Newest Sand Suction Dredging Boat Dredger for Sale Engineers Available to Service Machinery Overseas Customized Provided MAP
- Sand Dredging Machine 2021 Hot Newest Small 12 Inch Cutter Suction Dredger Engineers Available to Service Machinery Overseas MAP
Product Details
Condition: | New | Type: | Cutter Suction Dredger | Power Type: | Diesel |
Dredging Depth: | 10 m | Draught: | 40 cm | Place of Origin: | Shandong, China |
Brand Name: | KD | Model Number: | KDCSD | Dimension(L*W*H): | 12.5*4.6*1.3m |
Weight: | 40t | Certification: | ISO9001 | Warranty: | 1 year warranty |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Cutter Suction Dredger Commins Engine Avaliable1.SGS,ISO
2.Warman pump
3.ISO9001
4.Hydraulic control system
dredger vessel sand mining dredger
1.Features
A.Design according to customer's requriments.
B.Highly efficient with low cost, a good underwater dredging machine.
C.Simple,rapid assembly and dismantling
2.Basic parameter
dredger vessel sand mining dredger Basic Parameter | |||||||
Model | KDCSD200 | KDCSD260 | KDCSD300 | KDCSD350 | KDCSD400 | KDCSD450 | KDCSD500 |
Dredger Body | |||||||
Dimensions(L*W*H)m | 12.5*4.6*1.4 | 12.5*5.8*1.6 | 14.5*5.8*1.8 | 14.5*5.8*1.8 | 22*6.4*2 | 26*7*2 | 26*7.1*2.2 |
Engine room(m) | 7.5*2.25*1.4 | 8*2.8*1.6 | 9*3.2*1.8 | 9.5*3.2*1.8 | 12*3.4*2 | 14*3.4*2 | 14*3.5*2.2 |
Dredging data | |||||||
Standard dredging depth | 6-7m | 6-8m | 8-10m | 10-12m | 12-14m | 12-14m | 12-14m |
Pump model | 8/6” | 10/8” | 12/10” | 12/10” | 14/12” | 14/12” | 450WN |
Water flow | 450m3/h | 800m3/h | 1100m3/h | 1500m3/h | 1900m3/h | 2500m3/h | 3200m3/h |
Suction pipeline diameter(mm/inch) | 260 | 300 | 350 | 350 | 400 | 450 | 500 |
Discharge pipeline diameter(mm/inch) | 200 | 260 | 300 | 350 | 400 | 450 | 500 |
Devices | |||||||
Total power KW | 176kw | 258kw | 353kw | 480kw | 640kw | 930kw | 1200kw |
Generator set(kw) | 24 | 24 | 24 | 24 | 24 | 36 | 36 |
Cutter head | |||||||
Diameter (mm) | 850-30 | 950-40 | 1100-50 | 1200-80 | 1300-110 | 1500-120 | 1700-140 |
Winch(hydraulic) | |||||||
Ladder winches | JC-3000 | JC-4000 | JC-4000 | JC-6000 | JC-6000 | JC-10000 | JC-12000 |
Swing winch | JC-3000 | JC-4000 | JC-4000 | JC-6000 | JC-6000 | JC-8000 | JC-10000 |
Spuds | |||||||
Quantity | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
Spuds length*diameter(mm) | 8600*273 | 11000*300 | 13000*350 | 15000*377 | 17000*450 | 17000*550 | 17000*600 |
Spuds weight/pic | 900kg | 1500kg | 2000kg | 2500kg | 3900kg | 4500kg | 5000kg |
3. Equipment Component Show
Cutter head
Winch
Hydraulic Control System
Engine and Pump
Gear Box
Rubber hose,float and PE pipeline
4. Packaging & Shipping
Packaging Details: | package:in container or bulk |
---|---|
Delivery Detail: | 45-90 days after deposit |
5.Professional Services
Pre-sales service:
Be a good consultant and assistant to customers, to ensure our customer's investment rewarded with great profit.
1. enough details about the ores or slags shall be learned, sometimes a test is needed for some ores.
2. Equipment of right model is selected for customers.
3. Customized products and processing flow sheet can be designed and developed to meet customer's special needs,
4. Engineer could be sent to observe customer's working site to come up with an optimized solution accordingly.
On-sales service:
Every customer is respected and convenience and reliability will be provided. We are devoted to helping you to benefit as much as possible.
1. Inspection is a must before delivering of the goods.
2. Assistance to make a construction plan by supplying all drawings and data needed.
3. most favorable scheme for you with the guaranteed quality.
4. timely communication to make sure improvement of project and your requirement met.
After-sales service:
1. Installation, adjustment, and testing of equipment is available.
2. Train of technicians and workers at site is promised.
3. Service engineers will not leave until ensuring the whole line running well after the installation & adjustment is finished.
4. if any failure or question about the machines or the processing line, contact us and we are available at any time.
6.Company Introduction
Qingzhou Keda Mining machine Co,.LTD.
1). We are professional cutter suction dredger manufacture with patent in china.
2).All products have been certified by ISO9001-2008. and have been exported to Ghana, Bangladesh, Sultan, Korea and so on.
Certificate files
7.Contact Us
Welcome to visit our factory and please feel free to contact me.
Peter Pan
Skype:kedamachinery03
E-mail:sales03(@)
