1.Feature
The hydraulic cutter suction dredger can be customized according to your request.We have specialized technology and the research and development center.
The cutter suction dredger usually is non-propelled.
1.It is suitable for inland lakes and coastal port dredging,dredging channels or reservoirs.
2.The dredging equipment of the whole vessel adopts hydraulic drive,centralized control.
3.It uses the suction pipe front around the suction pipe installed reamer rotating device, will be cut and bottom sediment agitation, then through suction tube will heave up sediment materials, with the help of a strong force of pump, sediment materials to dump.
4. Its working process of the dredging, mud, disposal, etc, can be a time for completion, it is a kind of high efficiency, lower cost of dredger, underwater mining machinery is good.
2. Technical Parameters
Model | KDCSD400 | KDCSD500 |
Dredger Body |
|
|
Dimensions(L*W*H)m | 22*6.4*2 | 26*7.1*2.2 |
Engine room(m) | 12*3.4*2 | 14*3.5*2.2 |
Dredging data |
|
|
Standard dredging depth | 12-14m | 12-14m |
Pump model | 14/12” | 450WN |
Water flow | 1900m3/h | 3200m3/h |
Suction pipeline diameter(mm/inch) |
| 500 |
Discharge pipeline diameter(mm/inch) |
| 500 |
Devices |
|
|
Total power KW | 640kw | 1200kw |
Generator set(kw) |
| 36 |
Cutter head |
|
|
Diameter (mm) | 1300-110 | 1700-140 |
Winch(hydraulic) |
|
|
Ladder winches | JC-6000 | JC-12000 |
Swing winch | JC-6000 | JC-10000 |
Spuds |
|
|
Quantity |
| 2 |
Spuds length*diameter(mm) | 17000*450 | 17000*600 |
Spuds weight/pic | 3900kg | 5000kg |
3. Detailed Photograph
Accessories for dredgers
a. cutter head
b.Hydraulic contral system
c.Engine and pump
d.pipe line
e.supds
2.Within warranty period,we provide free repair if quality problems emerge.
3.Engerneers are avaliable to service oversea to assemble and test the machine according to the contract.
4.Free training of the first batch of operater proved, any question or problem about the products can be answered via online support,phone calls or on-sit support 24 hours.
1)Our products can design as customers' requirement and geographical condition.
The products are of a great variety including 800-1500m3/h.
2)We are a modern large-scale mine Small Gold Dredger ral processing equipment
manufacturer for research and development, engineering design, producing installation, commissioning and after sale service with the good CAD Aided Design R & D center
and physical mineral processing laboratory.
3)We attach the development of scientific research, and form strategic partnership
with the major research institutions. And we had established good cooperation with
Import and export trading company, established Shandong magnetic equipment
Research Instituting.
1.Dredgers
Cutter Suction Dredgers Bucket Chain Dredgers
Auto Pump Dredgers Jet Suction Dredger Gold dredgers
Certificate
customer visit
Yes, we are specialized manufacturer and have our own factory.
2. What's the main product of our company?
Our main product is the dredger and gold mining machine.
3.Can I visit your factory?
Yes, of course. We sincerely welcome you come and visit our factory any time.
