Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger

Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger photo-1
US$ 100,000 - 1,000,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Cutter Suction Dredger
Power Type:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Cutter Suction Dredger
Power Type Diesel
Dredging Depth 25 m
Draught 120 cm
Place of Origin Shandong, China
Brand Name KD
Model Number KDCSD
Dimension(L*W*H) 26000*6400*2000mm
Weight 50 t
Certification ISO9001:2008
Warranty One year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Watercourse Sand Dredging Equipment
1.PLC control system
2.Cummins engine
3.Warman pump
4.ISO9001, CCS, SGS

          Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger

Product Description

1.Feature

1).Good quality with ISO9001:2008, CCS, SGS. Reliable hydraulic system. Self-protection.

2).The dredging depth is up to 25 meters. The discharge distance is up to 1500 meters.

3).Large working capacity up to 1000 stere per hour. Large water flow 800-6000 stere per hour.

2.Basic Parameter



Model

KDCSD

200

KDCSD

260

KDCSD

300

KDCSD

350

KDCSD

400

KDCSD

500

Dredger Body













Dimensions(L*W*H)m

13*4.6*1.3

13*5.8*1.6

14.5*6*1.8

14.5*6*1.8

22*6.4*2

26*7.1*2.5

Engine Room(m)

7.5*2.2*1.4

8*2.8*1.6

9*3.2*1.8

9.5*3.2*1.8

12*3.4*2

14*3.5*2.5

Dredging Data













Dredging Depth

6-7m

6-8m

8-10m

10-12m

12-14m

12-14m

Pump Model

8/6”

10/8”

12/10”

12/10”

14/12

450WN

Water Flow(m3/h)

450

800

1100

1500

1900

3200

Discharge Pipeline Diameter(mm/inch)

200

260

300

350

400

500

Devices













Total Power(kw)

176

258

353

480

640

1040

Generator Set(kw)

24

24

24

24

24

36





3.Component



Cutter Head(Driven by hydraulic motor)

Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger



Winch (Driven by hydraulic motor)

Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger



Pump and Engine

Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger



Gear Box

Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger



Pump Station

Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger



Operation Room

Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger



Float and PE Pipeline

Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger

Packaging & Shipping

  Cutter Suction Dredger with Container

Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction DredgerWatercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger

Our Services

     1.Dredging project consulting.
    2.Making proper solution according to geological condition.
    3.Providing whole production line equipments.
    4.Dispatching engineer overseas guidance for equipments installation and testing.
    5.Training your local first batch workers.
    6.Help you to solve the problems during the equipment operation.

Company Information

Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger

    1.We are a modern large-scale machinery manufacturer devoting ourselves to the fields of desiting, sand pumping and gold mining with engineering design, producing, installation, commissioning and high quality after sale service.

    2.All our products have been certified by ISO9001 and many of our products have been exported to more than fifteen countries such as Fiji, Ghana, Bangladesh, Sultan, Korea, USA, Russia, India and so on.



Certification

Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger

Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger

Recent Success Cases

Watercourse Sand Dredging Equipment Brand China Supplier Hydraulic Cutter Suction Dredger

FAQ

1. Is our company a direct or indirect producer?— Our company is a direct producer.

2. What's the main product of our company?      — Our main product is cutter suction dredger.

3. Are our products certified or patented?           — Yes, we only provide certified products.

4. Can we offer good after sale service?             — Yes, the warranty of all our products is one year and all spare parts will be provided fast and cheap forever.
