1.Feature
The hydraulic cutter suction dredger can be customized according to your request.We have specialized technology and the research and development center.
The cutter suction dredger usually is non-propelled.
1.It is suitable for inland lakes and coastal port dredging,dredging channels or reservoirs.
2.The dredging equipment of the whole vessel adopts hydraulic drive,centralized control.
3.It uses the suction pipe front around the suction pipe installed reamer rotating device, will be cut and bottom sediment agitation, then through suction tube will heave up sediment materials, with the help of a strong force of pump, sediment materials to dump.
4. Its working process of the dredging, mud, disposal, etc, can be a time for completion, it is a kind of high efficiency, lower cost of dredger, underwater mining machinery is good.
2. Technical Parameters
Model | KDCSD260 |
Dredger Body |
|
Dimensions(L*W*H)m | 12.5*5.8*1.6 |
Engine room(m) | 8*2.8*1.6 |
Dredging data |
|
Standard dredging depth | 6-8m |
Pump model | 10/8” |
Water flow | 800m3/h |
Suction pipeline diameter(mm/inch) | 300 |
Discharge pipeline diameter(mm/inch) | 260 |
Devices |
|
Total power KW | 258kw |
Generator set(kw) | 24 |
Cutter head |
|
Diameter (mm) | 950-40 |
Winch(hydraulic) |
|
Ladder winches | JC-4000 |
Swing winch | JC-4000 |
Spuds |
|
Quantity | 2 |
Spuds length*diameter(mm) | 11000*300 |
Spuds weight/pic | 1500kg |
3. Detailed Photograph
a. cutter head
b.Hydraulic contral system
c.Engine and pump
2.Within warranty period,we provide free repair if quality problems emerge.
3.Engerneers are avaliable to service oversea to assemble and test the machine according to the contract.
4.Free training of the first batch of operater proved, any question or problem about the products can be answered via online support,phone calls or on-sit support 24 hours.
Certificate
Yes, we are specialized manufacturer and have our own factory.
2. What's the main product of our company?
Our main product is the dredger and gold mining machine.
3.Can I visit your factory?
Yes, of course. We sincerely welcome you come and visit our factory any time.
