Widely Used Cutter Suction Dredger for Desilting
1.Feature
1).Good quality with ISO9001:2008, CCS, SGS. Reliable hydraulic system. Lower cost.
2).The dredging depth is up to 40 meters. The discharge distance is up to1500 meters.
3).Large working capacity up to 1000 stere per hour. Larger water flow 800-6000 stere per hour.
2.Basic Parameter
Model | KDCSD 200 | KDCSD 260 | KDCSD 300 | KDCSD 350 | KDCSD 400 | KDCSD 500 |
Dredger Body |
|
|
|
|
|
|
Dimensions(L*W*H)m | 13*4.6*1.3 | 13*5.8*1.6 | 14.5*6*1.8 | 14.5*6*1.8 | 22*6.4*2 | 26*7.1*2.5 |
Engine Room(m) | 7.5*2.2*1.4 | 8*2.8*1.6 | 9*3.2*1.8 | 9.5*3.2*1.8 | 12*3.4*2 | 14*3.5*2.5 |
Dredging Data |
|
|
|
|
|
|
Dredging Depth | 6-7m | 6-8m | 8-10m | 10-12m | 12-14m | 12-14m |
Pump Model | 8/6” | 10/8” | 12/10” | 12/10” | 14/12” | 450WN |
Water Flow(m3/h) | 450 | 800 | 1100 | 1500 | 1900 | 3200 |
Discharge Pipeline Dia(mm) | 200 | 260 | 300 | 350 | 400 | 500 |
Devices |
|
|
|
|
|
|
Total Power(kw) | 176 | 258 | 353 | 480 | 640 | 1040 |
Generator Set(kw) | 24 | 24 | 24 | 24 | 24 | 36 |
3.Component
Cutter Head (Driven by hydraulic motor)
Winch (Driven by electric motor)
Warman Pump & Cummins Engine
Gear Box
Operation Room
Float and PE Pipeline
Cutter Suction Dredger with Container
1.Dredging project consulting.
2.Making proper solution according to geological condition.
3.Providing whole production line equipments.
4.Engineer overseas guidance for installation and testing.
5.Training your local first batch workers.
6.Help you to solve the problems during the equipment operation.
1.We are a modern large-scale machinery manufacturer devoting ourselves to the field of desilting, sand pumping and gold mining with engineering design, producing, installation, commissioning and high quality after sales service.
2.All our products have been certified by ISO9001 and many of our products have been exported to more than fifteen countries such as Fiji, Ghana, Bangladesh, Sultan, Korea, USA, Russia, India and so on.
Certification
Recent Success Cases
1. Is our company a direct or indirect producer?— Our company is a direct producer.
2. What's the main product of our company? — Our main product is cutter suction dredger.
3. Are our products certified or patented? — Yes, we only provide certified products.
4. Can we offer good after sale service? — Yes, the warranty of all our products is one year and all spare parts will be provided fast and cheap forever.
You are invited to create a bright future with us. Please contact!
Contact: Chance Ji
Mobile: +86 13780897802
Skype: kedamachinery07
E-mail: sales07(@)
