Specifications
Gold Vibtating Screen Plant1.5-10 years service life
2.Diesel power
3.ISO9001
4.Low using cost
Best Ability Gold Vibtating Screen Plant
1.Best Ability Gold Vibrating Screen Plant,Feature
1).Gold vibrating screen plant is widely used for gold mining,which is a good machine to help you get fine gold.
2).Gold recovery rate can be more than 90%.
3).Screen replaceable for different size stone.
4)Easy to control and low using cost.
2.Best Ability Gold Vibrating Screen Plant,Basic parameters
| Gold Vibrating Screen plant KDZS-150 | ||||||
| Performance | Capacity | 150t/h | ||||
| Max. Feeding Size | 400mm | |||||
| Dimension | L*W*H | 7800*3100*6200mm | ||||
| Vibrating screen | Size(L*W*H) | 5000*1800*1100mm | ||||
| Max Feeding Size | 200mm | |||||
| Layer | 2 | |||||
| Upper screen | ||||||
| Grizzly | steel bar | |||||
| Spacing | 50mm | |||||
| lower screen | Steel screen | |||||
| Mesh | 8mm | |||||
| Connection type | quick connection,Easy to replace | |||||
| Vibrator | Diameter of axle | 170mm | ||||
| Model | HM2-200L1-6-18.5 | |||||
| Motor | Power | 18.5kw | ||||
| Manufacturer | Shandong huali electric motor group co., Ltd | |||||
| Width(mm) | 3100mm | |||||
| Hopper | Length(mm) | 3300mm | ||||
| Baseplate | 8mmQ235 | |||||
| Side plate | 6mmQ235 | |||||
| Boundary dimension | 7630*2800*3970mm | |||||
| Frame | Chassis(Length * width) | 7630*550mm | ||||
| Quantity | 2 | |||||
| Form | The sled plate tilted at both ends,Can be dragged and moved | |||||
| Beams and columns material | 140mm Channel steel welding to buckle | |||||
| Chute | Gold chute with carpet | |||||
| Specifications(L*W * H * TH) | 6000*1000*150*3.75mm | |||||
| Coarse gold carpet | Mitsubishi brand ,4000mm length(Grab coarse particle gold) | |||||
| Fine gold carpet | Bend wire,2000mm length(Grab fine particles of gold) | |||||
| Quantity chute | 3 | |||||
3.Best Ability Gold Vibrating Screen Plant,Detail Introduce
The portable gold vibrating plant is popular for the some stone and no clay content in your mine.Working capacity is 150t/h,having a good adaptability in the outdoors.
Fixed Chute
Shaking chute
Shaking table
Amalgamator
Gold furnace
4.Best Ability Gold Vibrating Screen Plant, Shipping With Container
5.Guarantee and after-sale service
1).1 year warranty for import parts.
2).Profession technology provide installation,commissioning services.
3).24 hours technical support by e-mail or telephone.
Visiting
6.Our Company
1). We are profession gold mining equipment manufacture with patent in china.
2).All products have been certified by ISO9001-2008. and have been exported to Ghana, Bangladesh, Sultan, Korea and so on.
Certificate
7.Contact to me
June Ma
Skype:kedamachinery02
Tel/Fax:0086-536-3880600
Mob:0086-18353690657
Please contact to me with no hesitate, We are sure any of your inquiry will get our prompt attention and reply.
Thanks for your browse
